Extreme Networks 7254XSQ 10G SFP+ Managed Switch

Technical SpecificationsModel:7254XSQ Brand:Extreme Networks Product Type:1U rackmount fixed chassis Layer2/Layer3 managed switch Ports:48 ×10GBASE-X SFP+ slots,4 ×40GBASE-X QSFP+ uplink slots Switching capacity:1.28Tbps Forwarding rate:952Mpps MAC address table:128000 entries Jumbo frame:9216 bytes OS:ExtremeXOS Management interfaces:Serial console port,USB console,1×1G out-of-band management port Power & fan:Hot-swappable redundant PSU,hot-swappable fan trays,port-side to power-side airflow Operating temperature:0℃ ~ +40℃ Storage temperature:-40℃ ~ +70℃ Relative humidity:10%~90%, non-condensing Weight:7.6 kg

System compatibility7254XSQ belongs to Extreme Networks 7200 series data center switch family. Compatible with Extreme validated 10G SFP+ and 40G QSFP+ transceivers including SR,LR,ER and DAC/AOC cables. Supports stacking with other 7200 series switches. Widely used for data center top-of-rack server access and core aggregation spare replacement.

Function7254XSQ is a high-density 10G data center switch. It provides 48×10G SFP+ ports for server connections and 4×40G QSFP+ uplinks to core switches. It supports wire-speed Layer2 switching,Layer3 routing,MACsec encryption,VLAN,STP/RSTP/MSTP,LACP/MLAG,ACL,QoS,IPv4/IPv6 multicast and security policies. It monitors port optical status,SFP+/QSFP+ DDM diagnostics,system temperature,power consumption and hardware faults, and sends alarms. Used for data center ToR server access and aggregation layer networking.

InstallationMount the switch on standard 19-inch 1U rack. Install hot-swappable power supplies and fan trays. Install SFP+/QSFP+ transceivers and fiber/DAC/AOC cables. Connect console port for ExtremeXOS configuration. Verify boot,port optical link and routing function before commissioning.

Interface48×10G SFP+ slots,4×40G QSFP+ uplink slots,serial console port,USB console,out-of-band 1G management port,status LEDs,reset button,redundant PSU slots,fan trays,ground terminal,rack mounting ears for Extreme Networks 7254XSQ.

FeatureOriginal Extreme Networks 7200 series 1U rackmount high-density data center switch,48×10G SFP+ plus quad 40G QSFP+ uplink,MACsec port encryption,DDM optical monitoring,hot-swappable redundant power and fans,ExtremeXOS operating system,built-in self-diagnostic function. This spare supports legacy data center top-of-rack and aggregation high-speed network deployment.

DiagnosticSwitch fails to boot: check AC power input and PSU module health. Fiber port link down: verify SFP+/QSFP+ transceiver, fiber/DAC cable and port admin status. Optical low power alarm: inspect dirty fiber end faces or damaged cables. Transceiver no DDM data: confirm Extreme validated optical module. Over-temperature alarm: check fan tray operation and rack airflow,remove dust buildup.

Product Brief7254XSQ is Extreme Networks 7200 series 1U rackmount Layer3 managed data center switch with 48×10G SFP+ and 4×40G QSFP+ uplink ports,classic spare part for data center top-of-rack and aggregation high-speed network overhaul.

DisclaimerAll parameters are for reference only and shall not be used as the basis for quotation. Goods are scarce, overseas delivery lead time is 3-7 working days. It is only used for equipment maintenance and renovation.
