Extreme Networks 700103-00-04 Indoor Wireless Access Point

Technical Specifications

Model：700103-00-04 Brand：Extreme Networks Product Type: Enterprise indoor wireless access point

Radio & Antenna:

• Dual radio: 2.4GHz + 5GHz

• Built-in integrated internal antennas

• Supports multiple SSID for network segmentation

Ports & Indicators:

• 1 × 10/100/1000BASE-T Gigabit Ethernet RJ45 uplink port

• Reset button for factory default restore

• LED indicators for power, wireless radio, link and fault alarm

Power Supply:

• Powered by IEEE802.3af PoE

• No dedicated AC power adapter required

Mechanical & Environmental:

• Indoor enclosure design

• Operating temperature：0℃ ~ +50℃

• Ceiling or wall mounting bracket compatible

• Lightweight compact housing

Wireless & Security Features

• Security: WPA2, 802.1X authentication, MAC address filtering

• QoS: WMM Wi-Fi multimedia priority queue

• Management: Managed by ExtremeWireless controller or ExtremeCloud IQ

• Supports client roaming for seamless wireless mobility

System compatibility

700103-00-04 belongs to Extreme enterprise indoor AP family. Works with Extreme PoE switches such as X460-G2, AH-SR and ERS4900 series. Compatible with ExtremeWireless wireless controller platform and ExtremeCloud IQ cloud management system. Widely used for enterprise office, retail and campus indoor wireless coverage spare replacement.

Function

700103-00-04 is enterprise indoor wireless access point manufactured by Extreme Networks. It provides stable dual-band Wi-Fi coverage for indoor business environment. It supports multi-SSID network isolation, user authentication and seamless client roaming. Powered by PoE, it simplifies ceiling installation cabling. Centralized controller management enables batch configuration, firmware upgrade and wireless monitoring. Widely deployed for commercial building, retail store and office wireless network spare replacement.

Installation

Follow ESD protection procedure. Fix mounting bracket on ceiling or wall, clip AP onto bracket. Connect Ethernet cable to PoE switch port. Power up via PoE supply. Adopt AP into wireless controller or ExtremeCloud IQ, configure SSID, security policy and radio parameters. Verify wireless client access connectivity.

Interface

1×GE RJ45 uplink port,reset button,status LED indicators,internal integrated antennas for Extreme Networks 700103-00-04.

Feature

Original Extreme Networks 700103-00-04 indoor dual band wireless access point,PoE powered,controller/cloud managed,built-in antennas. This spare unit is used for enterprise indoor wireless coverage maintenance and hardware replacement.

Diagnostic

AP cannot boot: Check PoE switch power supply and Ethernet cable. Wireless clients unable to connect: Verify SSID, security encryption and controller configuration. Frequent client disconnection: Check radio channel planning and environmental interference. AP offline: Inspect uplink cable, management VLAN and controller network reachability. LED fault alarm: Check ambient temperature and PoE power budget.

Product Brief700103-00-04 is Extreme Networks indoor dual-band PoE wireless access point,controller managed,classic spare for enterprise indoor wireless network.

DisclaimerAll parameters are for reference only and shall not be used as the basis for quotation. Goods are scarce, overseas delivery lead time is 3-7 working days. It is only used for equipment maintenance and replacement.
