Eaton FDB45MF MCCB Unit

Feature & Principle

This thermal magnetic molded case circuit breaker can automatically cut off the circuit when overload or short circuit fault occurs, to protect cables and downstream electrical loads. It supports manual closing and opening for circuit isolation.

Specifications

Model: FDB45MF Brand: Eaton (Cutler-Hammer) Series: FDB Type: Molded case circuit breaker Trip type: Thermal magnetic Voltage: 600VAC Mounting: Fixed installation Protection: IP20 Certification: UL, CE

Components & Diagnostics

Trip unit, contact system, arc extinguishing chamber, operating handle, wiring terminal. Common faults: contact overheating, mechanical jamming, trip failure.

Product Brief

FDB45MF molded case circuit breaker, Eaton power distribution spare widely used in industrial control cabinet power loop protection.
