DANAHER MOTION MMC-SD-4 Servo Drive

Technical Specifications

Model：MMC-SD-4 Brand：DANAHER MOTION Product Type: MMC-SD series multi-axis digital smart servo amplifier for industrial motion control

Drive Feature: Control mode: Position / Speed / Torque control Axis quantity: Up to 4 independent servo axes Feedback device: Incremental encoder, resolver, high-resolution encoder Built-in function: Electronic gearing, camming, multi-axis synchronous interpolation

Electrical Parameters: Input voltage: 230VAC three phase Continuous output current per axis: 6A Peak output current per axis: 12A Control power supply: 24VDC

Mechanical & Structure: Housing: Heavy-duty metal rack mount enclosure Mounting: Cabinet rack mounting Cooling: Forced air cooling Protection class: IP20

Environmental: Operating temperature: 0℃ ~ +50℃ Ambient humidity:5~85% non-condensing Certification: UL, CE approved Weight: Approx 4.9kg

System compatibility

MMC-SD-4 belongs to DANAHER MOTION MMC-SD smart drive family. Compatible with DANAHER MOTION brushless servo motors and MMC motion controller platform. Suitable for multi-axis CNC equipment,cutting machinery and complex automated production lines requiring synchronous motion

.

Function

MMC-SD-4 is multi-axis digital smart servo amplifier manufactured by DANAHER MOTION. It executes multi-axis motion commands from upper motion controller and drives 4 servo motors independently or synchronously. Realizes closed-loop control via motor feedback signals, delivering high-precision coordinated movement for multi-axis applications. PiCPro software supports parameter configuration, auto-tuning and program editing.

Installation

Follow lockout/tagout safety procedure before installation. Mount MMC-SD-4 inside electrical cabinet rack. Connect main power cable,motor cables and feedback cables strictly follow DANAHER MOTION MMC-SD series hardware manual. Complete axis auto-tuning and synchronous motion test during commissioning.

Interface

Three-phase AC power terminals,multi-channel motor output terminals,encoder feedback ports,opto digital I/O,RS232 communication port,status LED indicators for DANAHER MOTION MMC-SD-4.

Feature

Original DANAHER MOTION MMC-SD-4 4-axis servo drive,multi-axis synchronous control,flexible feedback selection,rack mount design,support PiCPro programming,UL & CE certified. This spare unit is used for multi-axis CNC system control,motion system upgrade and hardware replacement.

Diagnostic

Drive alarm: Inspect overvoltage,undervoltage,overcurrent and overtemperature faults. Axis no movement: Check power wiring,encoder wiring and axis enable signal. Synchronization error: Re-tune servo parameters,check mechanical backlash and axis calibration. Abnormal vibration: Optimize control gains,inspect motor and coupling alignment.

Product Brief

MMC-SD-4 is DANAHER MOTION MMC-SD series 4-axis smart servo amplifier,supports multi-axis interpolation and camming functions,matched with Danaher brushless servo motors,classic spare part for multi-axis CNC and complex industrial automation motion system.
