DANAHER MOTION DSM-130 Servo Drive

Technical Specifications

Model：DSM-130 Brand：DANAHER MOTION Product Type: Centurion DSM series high power digital servo amplifier for industrial motion control

Drive Feature: Control mode: Position / Speed / Torque control Command input: ±10V analog, pulse & direction, master encoder input Built-in function: Electronic gearing, indexing motion, S-curve acceleration Peak shunt power: 4.5kW

Electrical Parameters: Input voltage: 230VAC three phase Continuous output current: 15A Peak output current: 30A Continuous output power: 3.0kW

Mechanical & Structure: Housing: Heavy-duty metal enclosure Mounting: Cabinet panel mounting Cooling: Forced air cooling Protection class: IP20

Environmental: Operating temperature: 0℃ ~ +50℃ Ambient humidity:5~85% non-condensing Certification: UL, CE approved Weight: Approx 3.0kg

System compatibility

DSM-130 belongs to DANAHER MOTION Centurion DSM servo drive family. Compatible with DANAHER MOTION high torque brushless synchronous servo motors and mainstream CNC / PLC controllers. Suitable for heavy load CNC machine tools,cutting equipment and large packaging machinery single-axis motion control.

Function

DSM-130 is high power digital servo amplifier manufactured by DANAHER MOTION. It receives motion commands from upper CNC or PLC controller and outputs high regulated power to servo motor. Closed-loop control is realized via encoder feedback to achieve high precision positioning and fast speed response. It supports multiple command interfaces and built-in motion functions for heavy-duty machine applications.

Installation

Follow lockout/tagout safety procedure before installation. Mount DSM-130 on electrical cabinet panel. Connect three-phase power cable, motor cable and encoder cable strictly follow DANAHER MOTION Centurion DSM series wiring manual. Complete motor auto-tuning and full-load motion test during commissioning.

Interface

3-phase AC power terminals, motor output terminals,encoder port,digital I/O terminals,RS232 communication port,status LED indicator for DANAHER MOTION DSM-130.

Feature

Original DANAHER MOTION DSM-130 Centurion high power servo drive,three phase input,large peak current,forced air cooling,multi command input interfaces,UL & CE certified. This spare unit is used for heavy-load CNC machine axis control,motion system upgrade and hardware replacement.

Diagnostic

Drive alarm: Inspect overvoltage, undervoltage, overcurrent and overtemperature faults. Motor no rotation: Check three-phase power wiring,encoder connection and drive enable signal. Positioning deviation: Re-tune servo gain,inspect encoder signal and mechanical backlash. Abnormal vibration: Adjust servo parameters,check motor and coupling alignment.

Product Brief

DSM-130 is DANAHER MOTION Centurion DSM high power digital servo amplifier,supports multi-mode control,matched with high torque Danaher brushless servo motors,classic spare part for heavy-duty CNC and industrial automation motion system.
