DANAHER MOTION M.1016.8879 Servo Drive

Technical Specifications

Model：M.1016.8879 Brand：DANAHER MOTION Product Type: M series digital servo amplifier for industrial motion control

Drive Feature: Control mode: Position / Speed / Torque control Command input: Pulse & direction, ±10V analog command Built-in function: Electronic cam, homing routine, S-curve acceleration PWM switching frequency: 8kHz

Electrical Parameters: Input voltage: 230VAC single phase Continuous output current: 9A Peak output current: 18A Control supply: 24VDC

Mechanical & Structure: Housing: Metal sheet enclosure Mounting: DIN rail mounting Cooling: Convection cooling Protection class: IP20

Environmental: Operating temperature: 0℃ ~ +50℃ Ambient humidity:5~85% non-condensing Certification: UL, CE approved Weight: Approx 1.7kg

System compatibility

M.1016.8879 belongs to DANAHER MOTION M series servo drive family. Compatible with DANAHER MOTION brushless synchronous servo motors and mainstream PLC motion controllers. Widely used for packaging equipment, material handling and CNC single-axis motion applications.

Function

M.1016.8879 is digital servo amplifier manufactured by DANAHER MOTION. It receives motion command signals from upper controller and outputs adjustable power to servo motor. Closed-loop control is realized through encoder feedback to achieve high-precision positioning and stable speed regulation. Built-in motion functions simplify equipment programming and commissioning.

Installation

Follow lockout/tagout safety procedure before installation. Mount M.1016.8879 on DIN rail inside electrical cabinet. Connect power cable, motor cable and encoder cable strictly follow DANAHER MOTION M series wiring manual. Complete motor auto-tuning and motion test during commissioning.

Interface

AC power terminals, motor output terminals, encoder port, digital I/O terminals, RS232 communication port, status LED indicator for DANAHER MOTION M.1016.8879.

Feature

Original DANAHER MOTION M.1016.8879 digital servo drive,multiple control modes,stable dynamic response,DIN rail installation,built-in motion functions,UL & CE certified. This spare unit is used for automation equipment axis control,motion system maintenance and hardware replacement.

Diagnostic

Drive alarm: Inspect overvoltage,undervoltage,overcurrent and overtemperature faults. Motor no rotation: Check power wiring,encoder connection and drive enable signal. Positioning deviation: Re-tune servo gain,inspect encoder signal and mechanical backlash. Abnormal vibration: Adjust servo parameters,check motor and coupling alignment.

Product Brief

M.1016.8879 is DANAHER MOTION M series digital servo amplifier,supports multi-mode control,matched with Danaher brushless servo motors,classic spare part for CNC and industrial automation motion system.
