DANAHER MOTION M-1008-0297 Servo Motor

Technical SpecificationsModel：M-1008-0297 Brand：DANAHER MOTION (Kollmorgen) Product Type: Permanent magnet synchronous brushless AC servo motor for industrial single-axis positioning applications

Motor Feature:3-phase synchronous servo motor with high energy density magnet Integrated high resolution incremental encoder for closed-loop feedback Built-in PTC thermal sensor for stator overheat protection Optional shaft holding brake Low cogging torque,smooth speed performance at low rotation speed Heavy-duty bearing structure for continuous cyclic operation

Electrical Parameters:Rated voltage:230VAC three phase Rated speed:3000 rpm Thermal class:F insulation Feedback:Differential line driver incremental encoder Thermal protection:PTC thermistor embedded in stator winding

Mechanical & Structure:Mounting:Flange mount with shaft keyway Shaft:Standard keyed output shaft Protection class:IP65

Environmental:Operating temperature:-20℃ ~ +40℃ Ambient humidity:5~85% non-condensing Certification:UL, CE approved Status:Discontinued legacy spare part

System compatibility

M-1008-0297 belongs to DANAHER MOTION Kollmorgen servo motor series. Compatible with Kollmorgen S200 / AKD series servo drives. Widely used in packaging machinery,cutting equipment and general automation positioning axes.

Function

M-1008-0297 is permanent magnet brushless servo motor manufactured by DANAHER Kollmorgen. It converts electrical power output from servo amplifier into precise rotary mechanical movement. Built-in encoder feeds real-time speed and position back to servo drive to realize closed-loop positioning control. Embedded PTC thermal sensor monitors winding temperature to prevent motor burnout during overload operation.

Installation

Follow lockout/tagout safety procedure before installation. Fix motor flange to mechanical base and align coupling carefully. Connect 3-phase power cable,encoder feedback cable and thermal sensor cable according to Kollmorgen hardware manual. Complete servo loop tuning and positioning test after mechanical assembly.

Interface

3-phase power connector,encoder feedback connector,PTC thermal sensor connector,shaft keyway for DANAHER MOTION M-1008-0297.

Feature

Original DANAHER MOTION M-1008-0297 brushless servo motor,IP65 protection,high resolution feedback encoder,embedded thermal monitoring,low cogging torque,robust bearing assembly,UL & CE certified. This spare unit is used for industrial automation equipment axis drive replacement and servo system maintenance.

Diagnostic

Motor no rotation:Check 3-phase power,encoder cable and servo enable signal. Overheat alarm:Inspect motor ventilation,load condition and PTC circuit. Position deviation or jitter:Check encoder wiring,coupling tightness and servo gain tuning.

Product Brief

M-1008-0297 is DANAHER MOTION Kollmorgen brushless AC servo motor,matched with Kollmorgen S200 and AKD servo amplifiers,legacy servo motor for industrial automation positioning axes.
