DANAHER MOTION 502-03427-00 DC Output Board

Technical SpecificationsModel：502-03427-00 Brand：DANAHER MOTION (Giddings & Lewis) Product Type: Rack plug-in DC digital output printed circuit board assembly for CNC motion control system

Board Feature:Function: Generate 24VDC digital output signals from CNC controller to machine field actuators, relays and solenoid valves Opto-coupler isolation between rack control bus and field output circuits On-board LED indicators for each channel real-time status monitoring Overcurrent and short-circuit protection for each output channel Gold finger edge connector for CNC rack backplane connection Surge and ESD protection circuit to prevent electromagnetic damage

Electrical Parameters:Backplane supply:+5VDC, ±15VDC supplied from CNC rack backplane Field output: 24VDC DC sink/source configurable output Galvanic isolation voltage:500V between control side and machine field side

Mechanical & Structure:Housing:PCB assembly with metal retention bracket Mounting:Plug-in installation into Giddings & Lewis CNC rack slot Protection class:IP20

Environmental:Operating temperature:0℃ ~ +50℃ Ambient humidity:5~85% non-condensing Certification:UL, CE approved Status:Manufacturer discontinued legacy spare part

System compatibility

502-03427-00 belongs to DANAHER MOTION Giddings & Lewis legacy CNC rack family. Compatible with older Giddings & Lewis CPU board, analog servo control boards and encoder feedback cards. Widely used on heavy-duty boring mills, vertical turning centers and horizontal machining centers.

Function

502-03427-00 is DC digital output PCB board manufactured by DANAHER MOTION Giddings & Lewis. It receives digital commands from CNC main processor, then switches 24VDC field outputs to drive machine relays, solenoids and auxiliary actuators. Optical isolation isolates CNC logic from machine side electrical surge. Channel LEDs help maintenance technicians quickly identify faulty output channels during machine troubleshooting.

Installation

Follow lockout/tagout safety procedure before installation. Cut off all power of CNC rack. Insert 502-03427-00 gold finger card into empty rack slot and lock retention bracket. Connect field actuator wiring to terminal block according to Giddings & Lewis hardware manual. After wiring, power on and test each output channel one by one.

Interface

Gold-edge backplane connector, field output terminal block, on-board channel status LED indicator for DANAHER MOTION 502-03427-00.

Feature

Original DANAHER MOTION 502-03427-00 DC output interface PCB board,opto-isolated 24VDC output,per-channel short-circuit protection,LED diagnostic indicators,gold finger rack plug-in design,anti-interference circuit,UL & CE certified. This spare unit is used for legacy heavy CNC machine I/O control system maintenance and hardware replacement.

Diagnostic

No output action: Check rack backplane power, channel enable signal and field wiring. Channel burnout: Inspect overload or short circuit of solenoid/relay load. Intermittent output failure: Verify cable shielding, grounding and surrounding electromagnetic interference.

Product Brief

502-03427-00 is DANAHER MOTION Giddings & Lewis legacy rack mount DC digital output PCB board,for driving machine relays and solenoids of heavy-duty CNC machine control system,discontinued spare card.
