DANAHER MOTION 401-34434-20 Servo Power Cable

Technical SpecificationsModel：401-34434-20 Brand：DANAHER MOTION (Giddings & Lewis) Product Type: Shielded servo motor power cable assembly for heavy-duty CNC machine servo axis

Cable Feature:Function: Transmit three-phase AC power from DSM servo amplifier to HD series servo motor Overall copper braid shielding for EMI noise suppression Pre-terminated connectors on both ends, ready for direct plug-in Oil resistant, abrasion resistant outer jacket for machine tool environment Conductor insulation with high dielectric strength

Electrical Parameters:Rated voltage:600VAC Conductor: Multi-strand tinned copper Shield: Continuous copper braid shield, 360° shield termination at connectors Insulation withstand voltage: Hi-pot tested

Mechanical & Structure:Outer jacket: Industrial flexible PUR cable sheath Termination: Factory assembled molded connectors at both ends Flexing performance: Suitable for continuous drag chain motion application Protection class:IP67 at connector mating face

Environmental:Operating temperature:-20℃ ~ +80℃ Ambient humidity:5~85% non-condensing Certification:UL, CE approved Status:Manufacturer discontinued legacy spare part

System compatibility

401-34434-20 is DANAHER MOTION Giddings & Lewis servo power cable. Matched with HD series heavy-duty servo motors and Centurion DSM servo drives. Widely used on large horizontal boring mills and vertical turning centers.

Function

401-34434-20 is factory pre-assembled shielded servo power cable manufactured by DANAHER MOTION. It delivers 3-phase drive power from servo amplifier to servo motor. The full copper braid shielding reduces electromagnetic interference between power circuit and encoder signal lines. Pre-crimped connectors reduce field wiring errors and shorten machine maintenance downtime.

Installation

Follow lockout/tagout safety procedure before installation. Confirm power is fully cut off on servo drive and motor. Route 401-34434-20 cable inside drag chain where applicable. Connect one end to servo drive power terminal and the other end to motor power connector. Secure cable strain relief and connect shield ground at cabinet side. Perform insulation resistance test before power-on commissioning.

Interface

Servo drive side power connector, motor side power connector, copper braid shielding for DANAHER MOTION 401-34434-20.

Feature

Original DANAHER MOTION 401-34434-20 servo power cable assembly,600V rating,full copper braid shielding,oil & abrasion resistant PUR jacket,pre-terminated connectors,UL & CE certified. This spare unit is used for Giddings & Lewis CNC machine servo axis power wiring replacement.

Diagnostic

Motor overcurrent alarm: Check cable insulation, connector pin short or damaged conductor. Intermittent axis fault: Inspect cable bend fatigue, shielding continuity and grounding connection. Insulation breakdown: Run megger test to detect internal conductor damage.

Product Brief

401-34434-20 is DANAHER MOTION Giddings & Lewis shielded servo motor power cable assembly,matched with HD servo motor and Centurion DSM drives,for heavy CNC machine axis power connection,legacy pre-terminated spare harness.
