804-5044B Isolated Signal Converter Unit

Feature & Principle

It receives analog 4-20mA input signal from field transmitters, uses optoelectronic isolation circuit to eliminate ground loop interference, outputs isolated standard 4-20mA signal to PLC or DCS for stable signal transmission.

Specifications

Model: 804-5044B Signal: 4-20mA input / 4-20mA output Isolation: Galvanic isolation Power supply: DC24V Mounting: DIN rail Protection: IP20 Certification: CE

Components & Diagnostics

Opto-isolation chip, signal conditioning PCB, power regulation circuit, terminal block, status indicator. Common faults: no signal output, signal deviation, ground interference, power input failure.

Product Brief

804-5044B signal isolator, process automation spare widely used for chemical, water and power plant analog signal isolation.
