Yaskawa DF9200658-C0N Interface Board

Technical Specifications

Model:DF9200658-C0N (JANCD-MIF01)

Brand:Yaskawa

Product type:Robot multi-function interface PCB board

Power supply:DC24V

Control function:Cross-board data exchange,signal conversion,peripheral interface expansion

Communication:Robot backplane bus,Mechatrolink bus

Mounting:Rack mount

Operating temperature:0~55℃

Relative humidity:5~95% non-condensing

Weight:0.60kg

Certification:CE

System compatibility

DF9200658-C0N belongs to Yaskawa legacy robot MRC controller family,matched with Yaskawa MRC robot controllers and CACR-SR series servo drives. Widely used in welding robots,material handling robots and special automation equipment. This is a discontinued legacy robot interface board for old production line maintenance spare replacement.

Function

DF9200658-C0N serves as high precision robot multi-function interface board. It realizes data interaction between robot main CPU board and peripheral functional boards,completes signal conversion and interface expansion. Built-in multi-level hardware protection to stabilize bus transmission. It supports high-speed data transmission among each internal module of robot controller.

Installation

Mount DF9200658-C0N inside robot controller cabinet. Complete backplane bus wiring according to wiring drawing. Verify bus communication status after power on.

Interface

‑Robot backplane bus connector

‑Internal module data port

‑Expansion signal connector

‑Onboard signal conversion and isolation circuit

Circuit feature

Compact rugged PCB layout,equipped with surge and ESD suppression circuit. Fast data transmission response,strong anti-interference performance for industrial cabinet environment. Standard factory firmware preloaded.

Feature

DF9200658-C0N is obsolete Yaskawa MRC robot series spare part. Typical failures include bus communication failure,signal conversion abnormality,port damage. Check board integrity before replacement. This board must match corresponding Yaskawa MRC robot controller,direct substitution without communication verification is not recommended.

Diagnostic

When bus communication interruption,signal conversion error or hardware fault occurs,the board triggers corresponding alarm codes and sends fault signal to robot main controller.

Built‑in function

Internal controller data exchange,multi-channel signal conversion,interface expansion,bus fault monitoring,used as robot multi-function interface board spare replacement.

Product Brief

DF9200658-C0N (JANCD-MIF01) is Yaskawa MRC robot series multi-function interface board for industrial robot and precision automation machinery. Confirm robot controller model matching before ordering. ESD protection required during handling and installation.
