Yaskawa CPS-10FB Power Supply Unit

Technical Specifications

Model:CPS-10FB

Brand:Yaskawa

Product type:Motion controller power supply module

Input voltage:AC200-230V single phase

Output:DC5V,DC24V

Cooling:natural air cooling

Mounting:Rack mount

Operating temperature:0~55℃

Relative humidity:5~95% non-condensing

Weight:1.1kg

Certification:CE

System compatibility

CPS-10FB belongs to Yaskawa MP motion control system family,matched with CG series control boards and CACR-SR series servo drives. Widely used in chip mounters,precision X-Y positioning platforms and special automation equipment. This is a discontinued legacy power supply unit for old production line maintenance spare replacement.

Function

CPS-10FB serves as dedicated power supply for motion control rack. It converts AC input into stable DC5V and DC24V power to supply main control board, I/O boards and communication modules. Built-in multi-level hardware protection including overvoltage,overcurrent and overheat protection to guarantee stable system operation.

Installation

Mount CPS-10FB in controller rack. Wire AC input and DC output cables according to wiring drawing. Complete power inspection before powering on the whole control system.

Interface

‑AC input terminal block

‑DC output terminals for controller backplane

‑Front panel LED power & fault status indicators

‑Onboard protection and monitoring circuit

Circuit feature

Compact rugged PCB layout,equipped with surge and ESD suppression circuit. Stable DC output,strong anti-interference performance for industrial cabinet environment.

Feature

CPS-10FB is obsolete Yaskawa MP series power supply spare part. Typical failures include power board damage,output failure and overheating faults. Check module integrity before replacement. Must match corresponding controller rack,direct substitution without hardware validation is not recommended.

Diagnostic

When overvoltage,overcurrent,overheat or output loss occurs,the module triggers alarm signals and sends fault status to upper controller.

Built‑in function

AC-DC power conversion,multi-level hardware fault protection,real-time power status monitoring,used as motion controller power supply spare replacement.

Product Brief

CPS-10FB is Yaskawa MP series rack power supply module for dedicated semiconductor and precision automation machinery. Confirm rack system matching before ordering. ESD protection required during handling and installation.
