XYCOM XVME-085 Prototyping Module

Technical Specifications

Model:XVME-085

Brand:XYCOM

Product type:VMEbus Universal Prototyping Module

Power supply:+5V VME backplane power

Bus interface:Standard VMEbus,slave communication

Form factor:Single-height VME card

Weight:0.4kg

Operating temperature:0℃ ~ +50℃

Storage temperature:-40℃ ~ +85℃

Relative humidity:5%~95%,non-condensing

Certification:CE,UL

System compatibility

XVME-085 belongs to XYCOM XVME series prototype module.

It installs in XYCOM VME chassis and cooperates with XVME series CPU and I/O modules.

Compatible with turbine,compressor and legacy DCS control systems via VME bus.

Commonly used for power plant,oil & gas,petrochemical old equipment maintenance and spare replacement.

Function

Universal prototype breadboard for VME rack custom circuit development and signal conditioning.

Provide large area prototyping grid for user soldering and custom circuit construction.

Realize custom signal conversion,signal conditioning and interface adaptation.

Connect custom circuit to VME backplane for data interaction with main CPU.

Onboard self-test for VME bus interface and basic power circuit fault inspection.

Installation

Power off VME chassis.

Insert XVME-085 card into empty VME slot,tighten front panel fixing screw.

Complete custom circuit wiring on prototyping grid.

Power on chassis,run hardware self-test.

VME CPU scans bus,identifies the board and starts custom circuit debugging.

Interface

VME P1 backplane connector,user prototyping grid terminals,LED indicators:PASS,FAULT.

Feature

Single height VME prototyping board,XYCOM XVME series proto module.

Large area solderable breadboard grid for user custom circuit design.

Standard VME slave interface,easy to integrate into existing VME rack.

Industrial grade PCB substrate,anti-vibration design.

Discontinued obsolete VME module,supply only for old production system spare replacement.

Vibration resistant PCB design,suitable for turbine control cabinet.

Diagnostic

FAULT LED on:board power circuit or VME bus interface damage;

Cannot be identified by CPU:check VME backplane contact and address jumper setting;

Custom circuit abnormal:check soldering point and wiring of prototyping area.

Product Brief

XYCOM XVME-085 is legacy VMEbus universal prototyping module.

It provides prototype breadboard space for custom signal circuit development in VME control rack,widely used as spare part for turbine and compressor control,petrochemical and power plant old DCS renovation.
