XYCOM PM101229 VME Interface Module

Technical Specifications

Model:PM101229

Brand:XYCOM

Product type:VMEbus Signal Interface Board (PMXVME-230)

Power supply:+5V VME backplane power

Bus interface:Standard VMEbus

Form factor:Single-height VME card

Weight:0.42kg

Operating temperature:0℃ ~ +50℃

Storage temperature:-40℃ ~ +85℃

Relative humidity:5%~95%,non-condensing

Certification:CE,UL

System compatibility

PM101229 belongs to XYCOM PMXVME-230 series VME interface board.

It installs in XYCOM VME chassis,cooperates with XVME series CPU and I/O modules.

Compatible with turbine,compressor and legacy DCS control systems.

Commonly used for power plant,oil & gas,petrochemical old equipment maintenance and spare replacement.

Function

Signal interface conversion module for VME rack control system.

Realize signal transmission and isolation between field equipment and VME backplane.

Complete digital and analog signal receiving,shaping and forwarding.

High speed data interaction with main CPU via VME bus.

Onboard self-test for signal circuit,data bus and VME bus interface fault inspection.

Installation

Power off VME chassis.

Insert PM101229 card into empty VME slot,tighten front panel fixing screw.

Check backplane connection.

Power on chassis,run hardware self-test.

Controller identifies the board and starts signal transmission function.

Interface

VME P1 backplane connector,field signal terminal,LED indicators:PASS,FAULT.

Feature

Single height VME interface board,marked as PMXVME-230.

Signal isolation design,suppress interference from industrial field.

Industrial grade circuit components,anti-vibration and stable operation.

VME slave interface,easy plug-in installation.

Discontinued obsolete VME module,supply only for old production system spare replacement.

Vibration resistant PCB design,suitable for turbine control cabinet.

Diagnostic

FAULT LED on:signal circuit damage or VME bus communication failure;

Cannot be identified by CPU:check VME backplane contact and slot status;

Signal transmission abnormal:check field wiring and signal conditioning circuit.

Product Brief

XYCOM PM101229 is legacy PMXVME-230 VMEbus signal interface board.

It serves as signal conversion and transmission channel between field devices and VME control rack,widely used as spare part for turbine and compressor control,petrochemical and power plant old DCS renovation.
