XYCOM 89086-002 Operator Interface Panel

Technical Specifications

Model:89086-002

Brand:XYCOM

Product type:VMEbus Industrial Operator Interface Panel

Power supply:+24V DC

Bus interface:Standard VMEbus

Form factor:Front panel operator terminal

Weight:0.8kg

Operating temperature:0℃ ~ +50℃

Storage temperature:-40℃ ~ +85℃

Relative humidity:5%~95%,non-condensing

Certification:CE,UL

System compatibility

89086-002 belongs to XYCOM legacy operator HMI panel series.

It matches XVME VME rack system,cooperates with XVME series CPU and I/O modules.

Compatible with turbine,compressor and legacy DCS control systems via VME bus.

Commonly used for power plant,oil & gas,petrochemical old equipment maintenance and spare replacement.

Function

Serve as local human machine interface for VME control rack.

Display real-time process data,alarm information and system status.

Support manual operation,parameter setting and control command input.

Communicate with VME main CPU through backplane to realize data interaction.

Onboard self-test for display,touch/keyboard circuit and VME bus interface fault inspection.

Installation

Power off VME chassis.

Mount 89086-002 panel to cabinet front frame.

Connect VME backplane cable and DC power wiring.

Power on chassis,run hardware self-test.

VME CPU scans bus,identifies the panel and starts HMI operation.

Interface

VME bus connector,DC power terminal,LED indicators:PASS,FAULT,POWER.

Feature

Industrial grade operator panel,XYCOM legacy HMI product.

Stable display and input function,suitable for industrial cabinet installation.

Built-in EMC protection,suppress industrial electromagnetic interference.

VME bus communication,seamless match XVME CPU rack.

Discontinued obsolete operator panel,supply only for old production system spare replacement.

Vibration resistant design,suitable for turbine control cabinet.

Diagnostic

FAULT LED on:display circuit or communication circuit failure;

Cannot be identified by CPU:check VME cable connection and address jumper setting;

Screen abnormal:check power supply and display driving circuit.

Product Brief

XYCOM 89086-002 is legacy VMEbus industrial operator HMI panel.

It provides on-site data display and manual operation function for VME control rack,widely used as spare part for turbine and compressor control,petrochemical and power plant old DCS renovation.

Disclaimer

Product parameters are for reference only and shall not be used as pricing basis. Goods are in short supply and will be powered on for inspection before shipment. Overseas delivery lead time is 3-7 working days. The product is only used for equipment maintenance and transformation.
