Woodward 5437-092 NetCon Expansion Chassis Power Supply Module

Technical Specifications

Model:5437-092

Brand:Woodward

Product type:NetCon expansion chassis power supply module

Power supply:Input 18~32Vdc,output 24Vdc

Control function:Stable DC power output,overvoltage/overcurrent/short-circuit protection,power status monitoring,fault alarm signal output

Communication:Backplane bus for status feedback

Mounting:Plug-in rack mounting

Operating temperature:-20~60℃

Relative humidity:5~95% non-condensing

Weight:4.33kg

Certification:CE,UL

System compatibility

5437-092 belongs to Woodward NetCon turbine control system family,matched with NetCon expansion chassis and I/O modules.Widely used in gas turbine,steam turbine and generator control cabinets.This is a discontinued legacy expansion chassis power supply module for power unit maintenance spare replacement.

Function

5437-092 serves as Woodward NetCon expansion chassis power supply module.It supplies regulated 24V DC power for all I/O boards installed in NetCon expansion rack.It integrates complete protection circuits including overvoltage,overcurrent and short-circuit protection.The module uploads operating status and fault information to main controller through rack backplane bus.It is the core power supply component for NetCon expansion rack of turbine control system.

Installation

Insert 5437-092 into the designated slot of NetCon expansion chassis and lock the handle.Complete input DC power wiring according to wiring drawing.Check input voltage and cabinet grounding before power-on.

Interface

‑Rack backplane bus connector

‑DC input terminal block

‑Power status LED indicator

‑Fault alarm output terminal

Circuit feature

Isolated DC conversion circuit,built-in surge and ESD suppression design.Stable power output,strong anti-interference performance for power plant cabinet environment.

Feature

5437-092 is obsolete Woodward series spare part.Typical failures include no power output,voltage drift,overcurrent shutdown,fault indicator alarm.Check power circuit and backplane connector pins before replacement.This module must match NetCon expansion chassis,direct substitution without inspection is not recommended.

Diagnostic

When power loss,output abnormal or internal hardware fault occurs,the module triggers system power fault alarm and reports fault code to main controller.

Built‑in function

Expansion chassis I/O board power supply,overload and short-circuit protection,power operating status monitoring,used as Woodward NetCon series rack power supply module spare replacement.

Product Brief

5437-092 is Woodward old turbine series NetCon expansion chassis power supply module for gas/steam turbine generator sets and power automation equipment.Confirm NetCon rack model matching before ordering.ESD protection required during handling and installation.
