Woodward 5416-351 NetCon Cordset Cable

Technical Specifications

Model:5416-351

Brand:Woodward

Product type:NetCon bus cordset cable

Power supply:Not required

Control function:NetCon bus signal transmission,interconnection between main controller and remote I/O modules,signal noise suppression,shielding protection

Communication:NetCon serial bus

Mounting:Cabinet wiring

Operating temperature:-40~70℃

Relative humidity:5~95% non-condensing

Weight:0.28kg

Certification:CE,UL

System compatibility

5416-351 belongs to Woodward NetCon turbine control system family,matched with 505 / NetCon turbine controllers and I/O modules.Widely used in gas turbine,steam turbine and generator control cabinets.This is a discontinued legacy NetCon bus cordset cable for power unit maintenance spare replacement.

Function

5416-351 serves as high precision Woodward NetCon bus cordset cable.It connects main governor controller and distributed I/O modules,transmitting control commands and field collected operating data between master and slave stations.It adopts shielded twisted pair construction to reduce electromagnetic interference,ensuring stable bus communication in power plant harsh environment.It acts as the core data transmission link of Woodward NetCon turbine generator control system.

Installation

Lay 5416-351 inside turbine control cabinet.Complete connector wiring according to wiring drawing.Confirm shielding grounding is properly connected before power-on.

Interface

‑NetCon bus integrated plug connector

‑Shield ground terminal

‑Shielded twisted pair cable

Circuit feature

Shielded twisted pair cable structure,equipped with ESD and surge suppression design.Stable signal transmission,strong anti-interference performance for power plant cabinet environment.

Feature

5416-351 is obsolete Woodward series spare part.Typical failures include cable insulation aging,connector poor contact,shielding layer damage,communication timeout.Check cable body and connector pins before replacement.This cable must match corresponding Woodward NetCon system,direct substitution without inspection is not recommended.

Diagnostic

When communication interruption,data loss or intermittent disconnection occurs,the cable triggers corresponding alarm signals and sends fault message to turbine control system.

Built‑in function

NetCon bus data transmission,controller and remote I/O interconnection,electromagnetic noise shielding,used as Woodward NetCon series cordset communication cable spare replacement.

Product Brief

5416-351 is Woodward old turbine series NetCon cordset communication cable for gas/steam turbine generator sets and power automation equipment.Confirm controller model matching before ordering.ESD protection required during handling and installation.
