VMIC 332-001150-102 Industrial Assembly332-001150-102 Industrial Assembly

Module Feature

332-001150-102 is a high-reliability industrial assembly manufactured by VMIC, designed for installation inside automated machinery and motion control cabinets. The assembly adopts rugged construction to adapt to workshop vibration, dust and temperature fluctuation environments. Internal circuit components are screened for industrial grade, with stable electrical performance and long service life. It is commonly used as replacement spare for VME system peripheral circuit assembly, matching VMIC VME board series. Standard mounting holes for secure chassis installation, connector pin definition matches original equipment wiring harness. Widely used in semiconductor manufacturing equipment, precision machine tools and automated production line maintenance.

Working principle

The assembly acts as signal transmission and auxiliary power conditioning unit within the VME system. It routes control signals, feedback signals and auxiliary power between VME CPU board and peripheral I/O modules, suppresses electrical interference and protects internal circuit from transient surge. It cooperates with VMIC VME modules to complete bus signal distribution and signal level conversion.

Onboard components

Custom printed circuit board, surface mount signal conditioning chips, transient surge suppression components, industry grade connectors, mounting metal bracket, wiring terminal pins.

LED indicators

Equipped with power status LED, used to indicate whether the assembly is powered normally.

Hardware self-diagnosis

Visual inspection of PCB, solder joints, connector pins and mounting bracket; continuity test for each pin channel; insulation resistance test between signal circuit and ground; power-on functional test with matched VMIC VME system.

Programming software

No dedicated configuration software, works together with VMIC VME debugging software for whole system status verification.

Electrical & Process Parameters

Model: 332-001150-102 Brand: VMIC Device type: Industrial VME peripheral assembly Control mode: Passive signal transmission and surge protection Power supply: Matched with VME chassis auxiliary power Cooling: Convection cooling Protection: Transient surge suppression, overcurrent protection, ESD protection Mounting: Cabinet bracket mounting Protection class: PCB with optional conformal coating

Mechanical & Structure

Mounting: Cabinet bracket installation Protection class: PCB with optional conformal coating

Environmental

Operating temperature: 0℃ ~ +55℃ Storage temperature: -40℃ ~ +85℃ Ambient humidity: 5~95% non-condensing Certification: CE compliant Status: VMIC VME peripheral industrial spare assembly

Installation

Follow ESD safety procedure before handling. Fully power off the machine equipment. Fix 332-001150-102 assembly on cabinet mounting bracket. Align and plug in the matched wiring harness connectors. Check all wiring for short circuit risk. Power on equipment, run VMIC VME system self-check to verify signal communication before commissioning.

Interface

Multi-pin signal connectors for VME bus and peripheral signal, auxiliary power pins, ground terminal.

Diagnostic

No power LED light: abnormal auxiliary power supply or connector loose contact. Signal communication interrupt: damaged wiring harness, PCB circuit open circuit or connector pin corrosion. Random signal interference: poor grounding or surge suppression component degradation.

Product Brief332-001150-102 VMIC industrial VME peripheral assembly,signal transmission and surge protection function,for semiconductor equipment and precision machine tool VME control system maintenance and spare replacement.
