SIEB & MEYER 0610520KF12424 3B Servo Power Cable

Module Feature

SIEB & MEYER 0610520KF12424 3B is a pre-assembled shielded high-flex servo power cable. It is specially designed for the connection between SIEB & MEYER servo power module and servo motor. Multi-core twisted structure with overall copper shielding, excellent EMC anti-interference capability. Wear-resistant, oil-resistant and bending-resistant outer jacket, suitable for continuous dynamic bending applications in automation equipment. Pre-terminated connectors at both ends for fast and reliable field installation. Widely used in CNC machine tools, semiconductor processing equipment and high-precision automation production lines.

Working principle

Transmits three-phase AC power from servo power module to servo motor. The overall shield effectively suppresses electromagnetic interference generated by high-speed switching of the servo drive, preventing signal distortion of nearby encoder and control cables. The multi-core conductors carry motor phase current reliably under repeated bending movement.

Onboard components

Multi-core twisted power conductors, copper braided shielding layer, oil resistant outer jacket, molded metal connector assembly, strain relief structure.

LED indicators

No LED indicators.

Hardware self-diagnosis

Visual inspection of cable jacket for cracks, abrasion and connector damage; continuity test of each power core; insulation resistance test between conductors and shield; check shield grounding integrity.

Programming software

No dedicated configuration software.

Electrical & Process Parameters

Model: 0610520KF12424 3B Rated voltage: 600V Conductor: Multi-strand flexible copper Shield: Copper braid shield Bending characteristic: High flex continuous bending Cooling: Natural ambient Protection: Oil resistant, abrasion resistant Mounting: Cable routing installation

Mechanical & Structure

Mounting: Cable tray / drag chain routing Protection class: IP67 at connector mated state

Environmental

Operating temperature: -20℃ ~ +80℃ Ambient humidity: 5~95% non-condensing Certification: CE compliant Status: SIEB & MEYER high flex servo power cable assembly

System compatibility

Compatible with SIEB & MEYER servo power modules and matched servo motors for CNC and semiconductor motion drive systems.

Function

0610520KF12424 3B servo power cable manufactured by SIEB & MEYER. It transfers three-phase power from power module to servo motor. The shielding reduces electromagnetic noise to protect nearby weak signal circuits. Cable insulation damage, poor connector contact or shield disconnection will cause drive alarm or unstable motor operation. It is essential wiring component for high precision servo motion system.

Installation

Follow lockout/tagout safety procedure before installation. Cut off all system power completely. Route cable inside drag chain or cable tray, reserve bending radius, avoid sharp edge friction. Connect both end connectors to power module and motor securely, ensure shield ground connection. Power on and verify motor operation before formal operation.

Interface

Servo drive power connector, servo motor power connector, shield grounding terminal of 0610520KF12424 3B.

Diagnostic

Motor no rotation: Broken core wire, loose connector or no power output from drive. Drive overcurrent alarm: Cable insulation breakdown or short circuit between phases. Electromagnetic interference: Poor shield grounding or damaged shielding layer. Intermittent fault: Connector loose, cable fatigue fracture from repeated bending. Jacket damage: Abrasion by sharp mechanical parts.

Product Brief

0610520KF12424 3B SIEB & MEYER high flex shielded servo power cable,600V rated voltage,pre-terminated connectors,suitable for drag chain installation,used for connecting SIEB & MEYER servo drive and motor in CNC and semiconductor equipment.
