SEW MA-5015-FD-00 Cooling Blower Fan

Technical SpecificationsModel:MA-5015-FD-00 Brand:SEW Product Type:DC Centrifugal Blower Fan Dimension:50mm50mm15mm Bearing:Double ball bearing Mounting:Standard 4-hole fixed installation Operating temperature:-10℃ ~ +60℃ Storage temperature:-40℃ ~ +85℃ Relative humidity:5%~85%,non-condensing Certification:CE

System compatibilityMA-5015-FD-00 is SEW original 5015 series centrifugal blower. It is designed for SEW MOVITRAC and MOVIDRIVE series small power inverter and servo drive. Widely used on conveyor, packaging and material handling automation equipment, as direct replacement spare part for SEW drive internal cooling system.

FunctionThis centrifugal blower provides forced air cooling for power electronic components inside SEW inverter and servo drive. It dissipates heat generated by IGBT power module during continuous operation, prevents over-temperature alarm and drive shutdown, guarantees stable long-time running of the SEW drive unit.

InstallationDisconnect power supply before installation. Fix the fan with matching screws on the reserved mounting holes of SEW drive. Align air outlet to target heating components. Check wiring polarity strictly, wrong polarity will cause fan not running. Reserve air inlet and outlet space to avoid airflow blockage.

Interface2Pin DC power lead wire.

FeatureSEW MA-5015-FD-00 compact 5015 centrifugal blower, specially designed for limited internal space inside SEW frequency converter. Double ball bearing design, low vibration and long service life. Reliable forced convection cooling for SEW industrial drives. Discontinued legacy spare part, only for SEW drive cooling fan maintenance replacement. Suitable for small SEW MOVITRAC and MOVIDRIVE drive heat dissipation.

DiagnosticFan no rotation: power supply missing or reverse wiring; Abnormal rattling noise: bearing wear or foreign object stuck inside; Low airflow: dust accumulated on fan wheel and air duct; Intermittent stop: aging bearing or overheat protection triggered.

Product BriefSEW MA-5015-FD-00 is 50×50×15mm DC centrifugal blower fan, original spare part for SEW MOVITRAC and MOVIDRIVE inverters, used for forced cooling, dissipate power module heat and prevent over-temperature fault.

DisclaimerAll parameters are for reference only and not the basis of quotation. Goods are scarce,overseas delivery lead time 3-7 working days. It is only used for equipment maintenance and retrofit.
