SEW FBQ31C-01 Remote Mounting Kit

Technical SpecificationsModel:FBQ31C-01 Brand:SEW Product Type:Keypad Remote Mounting Frame Kit Material:Plastic housing + sealing gasket Cutout dimension:142mm × 90mm Cable:Matching extension cable for keypad Protection class:IP54 (when properly installed with gasket) Operating temperature:0℃ ~ +50℃ Storage temperature:-40℃ ~ +85℃ Relative humidity:5%~85%,non-condensing Certification:CE

System compatibilityFBQ31C-01 belongs to FBQ31C series mounting accessory,specially designed for FBG31C series operator keypads. Compatible with MOVITRAC 31C full range inverters. It allows moving the keypad from inverter front panel to cabinet door. Widely used for conveyor,packaging and material handling automation equipment,legacy SEW drive system maintenance and spare replacement.

FunctionThis cabinet door mounting kit enables remote installation of FBG31C keypad on control cabinet door. Operators can access inverter parameters,monitor running status and perform fault reset without opening the cabinet. Equipped with sealing gasket to keep dust and splash out,protect keypad in workshop environment. Cooperates with dedicated extension cable to realize signal transmission between keypad and inverter.

InstallationCut off inverter main power before installation. Cut matching opening on cabinet door,place FBQ31C-01 frame and fasten fixing clips. Install FBG31C keypad into the mounting frame. Connect extension cable between keypad and inverter front X4 port. Check gasket sealing to ensure IP rating. Power on inverter after wiring completion.

InterfaceExtension cable connector for FBG31C keypad and MOVITRAC 31C inverter X4 port.

FeatureSEW FBQ31C-01 cabinet door remote mounting kit for FBG31C keypad. Simple cabinet cutout installation,convenient for field operation. Built-in rubber gasket for dust and splash resistance. Keep original keypad full function after remote extension. Discontinued legacy spare part,only for FBQ31C mounting accessory maintenance replacement. Suitable for automation cabinet door local operation of MOVITRAC 31C drives.

DiagnosticKeypad no display after remote install: extension cable damaged or poor connector contact; Communication intermittent: cable interference,shield grounding not well; Water/dust ingress: gasket aging or frame not fully locked; Keypad loose: mounting clips broken.

Product BriefSEW FBQ31C-01 is FBQ31C series cabinet door mounting kit,used for remote installation of FBG31C keypad on control cabinet door,matched with MOVITRAC 31C inverters for convenient on-site operation.
