Rexroth CLC-V02.3-C-1 VME Multi-axis Motion Control Card Spare Part

Technical Specifications

Model:CLC-V02.3-C-1

Brand:Rexroth

Part No:R911271010

Product type:VME bus plug-in multi-axis motion control card

Input voltage:24V DC control power

Dimension:100mm160mm235mm

Weight:1.42kg

Communication:SERCOS fiber optic bus,serial host interface,VME backplane bus

Mounting:VME rack slot installation

Protection class:IP20

Operating temperature:0~45℃

Storage temperature:-20~70℃

Relative humidity:5~95% non-condensing

Certification:CE

LED indicators:Power,Run,Error,Bus activity

System compatibility

CLC-V02.3-C-1 belongs to Rexroth Indramat CLC motion control family,fits VME type control rack,compatible with CDB servo drives and 2AD series servo motors,widely used in packaging machinery,robotics,textile machines and material handling equipment.This is a legacy spare part for industrial equipment maintenance replacement.

Function

CLC-V02.3-C-1 is VME bus based motion control card for Indramat CNC servo system.It performs multi-axis interpolation,electronic cam and electronic line shafting,transmits real-time motion commands to servo drives via SERCOS fiber optic bus.It executes motion programs,axis synchronization and logic processing,realizes coordinated multi-axis movement for machine automation.

Installation

Insert CLC-V02.3-C-1 into the designated VME rack slot.Lock the card securely.Connect VME backplane bus and SERCOS fiber cables.Check optical fiber connection and shielding before power-on commissioning.

Interface

‑24V DC backplane power supply

‑SERCOS fiber optic transceiver port

‑Serial host communication port

‑VME backplane bus connector

‑Shield grounding terminal

Circuit feature

High-speed motion interpolation circuit,built-in bus signal isolation and surge suppression circuit,SERCOS optical decoding circuit,battery backed memory for program storage,strong anti-interference for high precision synchronous motion.

Feature

CLC-V02.3-C-1 is obsolete Rexroth spare part.Typical faults:VME backplane contact oxidation,optical port failure,battery data loss,main control chip damage,power circuit burnout.Inspect optical communication and firmware matching before replacement.

Diagnostic

When card fails,Power LED on,Run LED off,Error LED lit,SERCOS fiber link broken,axis initialization failure,motion program lost,multi-axis communication timeout alarm.

Built‑in function:Multi-axis motion interpolation,SERCOS fiber real-time communication,electronic cam control,electronic line shafting,program storage,host data exchange,used as Rexroth Indramat motion control system spare replacement.

Product Brief

CLC-V02.3-C-1 is Rexroth Indramat CLC series VME bus motion control card,works with CDB servo drives and 2AD servo motors.Verify VME rack compatibility and firmware version before ordering.ESD protection required during handling and installation.
