Rexroth CLC-D02.3FWA-CLC/DP-SY-06VRS-MS Motion Control Card Spare Part

Technical Specifications

Model:CLC-D02.3FWA-CLC/DP-SY-06VRS-MS

Brand:Rexroth

Part No:R911272056

Product type:plug-in multi-axis motion control card with preloaded firmware

Input voltage:24V DC control power

Dimension:80mm155mm210mm

Weight:1.30kg

Communication:SERCOS fiber optic bus,serial host port

Mounting:CCD rack slot installation

Protection class:IP20

Operating temperature:0~45℃

Storage temperature:-20~70℃

Relative humidity:5~95% non-condensing

Certification:CE

LED indicators:Power,Run,Error,Bus status,7-segment code display

System compatibility

CLC-D02.3FWA-CLC/DP-SY-06VRS-MS belongs to Rexroth Indramat CLC motion control family,fits CCD control rack,compatible with CDB servo drives and 2AD series servo motors,widely used in packaging machinery,robotics,textile machines and material handling equipment.This is a legacy spare part for industrial equipment maintenance replacement.

Function

CLC-D02.3FWA-CLC/DP-SY-06VRS-MS is a rack-mounted motion control card with pre-installed SY firmware version.It performs multi-axis interpolation,electronic cam and line shafting functions,transmits real-time motion commands to servo drives via SERCOS fiber bus.It executes motion programs,axis synchronization and logic processing,handles host communication and fault diagnosis for CNC motion system.

Installation

Insert CLC-D02.3FWA-CLC/DP-SY-06VRS-MS into the designated slot of CCD control rack.Lock the card securely.Connect backplane bus and SERCOS fiber cables.Check optical fiber connection and shielding before power-on commissioning.

Interface

‑24V DC backplane power supply

‑SERCOS fiber optic transceiver port

‑Serial host communication port

‑Internal backplane bus connector

‑Shield grounding terminal

Circuit feature

High-speed motion calculation circuit,built-in bus signal isolation and surge suppression circuit,SERCOS optical communication decoding circuit,battery backed SRAM for program storage,strong anti-interference for high precision synchronous motion.

Feature

CLC-D02.3FWA-CLC/DP-SY-06VRS-MS is obsolete Rexroth spare part.Typical faults:backplane contact oxidation,optical port failure,battery data loss,calculation chip damage,power circuit burnout.Inspect firmware version and optical communication before replacement.Firmware version must match system configuration.

Diagnostic

When card fails,Power LED on,Run LED off,Error LED lit,SERCOS fiber link broken,axis initialization failure,motion program lost,multi-axis communication timeout alarm,7-segment error code display.

Built‑in function:Multi-axis motion interpolation,SERCOS fiber real-time communication,electronic cam control,electronic line shafting,program storage,host data exchange,factory preloaded firmware,used as Rexroth Indramat motion control system spare replacement.

Product Brief

CLC-D02.3FWA-CLC/DP-SY-06VRS-MS is Rexroth Indramat CLC series motion control card preloaded with SY version firmware,installed in CCD rack and paired with CDB servo drives and 2AD servo motors.Verify firmware version and rack compatibility before ordering.ESD protection required during handling and installation.
