Rexroth 3TM15.2-TA-VA-TA-WE-MA-2EA Operator Panel Spare Part

Technical Specifications

Model:3TM15.2-TA-VA-TA-WE-MA-2EA

Brand:Rexroth

Product type:Indramat BTM15 series modular machine operator panel

I/O allocation:16 digital inputs,16 digital outputs

Communication interface:INTERBUS-S

Front protection grade:IP65

Color:RAL7035 light grey

Dimension:407mm169mm100mm

Weight:2kg

Operating temperature:0~45℃

Storage temperature:-20~70℃

Relative humidity:5~95% non-condensing

Certification:CE

Module configuration:Writeable keyboard module,feed override module,setup module,blind plate

System compatibility

3TM15.2-TA-VA-TA-WE-MA-2EA belongs to Rexroth Indramat BTM15 operator panel family,matched with Indramat CNC and motion control systems.Widely applied in CNC machining centers,milling machines and automation production lines.This is a discontinued legacy spare part for equipment maintenance replacement.

Function

3TM15.2-TA-VA-TA-WE-MA-2EA is a modular machine operator panel.It realizes man-machine interaction,operation command input and equipment status display for machine tools.Through INTERBUS-S fieldbus,it performs cyclic data exchange of 16DI/16DO with the host control system.It integrates writeable keyboard,feed override and setup function modules,supports spindle speed and feed rate adjustment,emergency stop operation and parameter setting,acting as local operation station for industrial CNC equipment.

Installation

Mount 3TM15.2-TA-VA-TA-WE-MA-2EA on machine cabinet panel,tighten fixing fasteners.Connect INTERBUS-S communication cable and power supply cable according to wiring diagram.Check terminal connection integrity before power-on commissioning.

Interface

‑INTERBUS-S bus connector

‑Power supply terminal

‑Digital I/O terminal block

Circuit feature

Modular integrated circuit design,stable bus communication,strong anti-interference,suitable for harsh workshop industrial environment.

Feature

3TM15.2-TA-VA-TA-WE-MA-2EA is obsolete Rexroth spare part.Typical faults:bus communication failure,key malfunction,encoder module damage,I/O channel damage,circuit aging.Inspect panel,communication port and I/O channel before replacement.This operator panel must match corresponding Indramat control system,direct substitution without inspection is not recommended.

Diagnostic

When communication failure,key unresponsive or I/O signal loss occurs,the control system will trigger alarm and stop related machine operation.

Built‑in function:Machine local operation,feed/spindle override adjustment,parameter setting,running status display,digital signal input & output,used as Rexroth Indramat CNC system spare replacement.

Product Brief

3TM15.2-TA-VA-TA-WE-MA-2EA is Rexroth Indramat discontinued modular operator panel with INTERBUS-S bus,equipped with multi-function module combination for CNC machine local operation and signal interaction.Confirm system compatibility,panel mounting size and bus protocol before ordering.ESD protection required during handling and installation.
