Rexroth 06-08750101 Spare Part

Technical Specifications

Model:06-08750101

Brand:Rexroth

Product type:Servo motor power cable

Power supply:Shielded high-current power line

Control function:Three-phase power transmission for tightening servo motor,stable power supply,anti-interference transmission

Communication:Power transmission

Mounting:Fixed wiring routing

Operating temperature:0~70℃

Storage temperature:-25~80℃

Relative humidity:5~95% non-condensing

Max working altitude:2000m

Weight:0.58kg

Dimension:3000mm10mm10mm

Certification:CE

Protection class:IP65

System compatibility

06-08750101 belongs to Rexroth servo nutrunner tightening system family,matched with tightening servo spindle and drive controller.Widely applied in automobile assembly bolt tightening workstations.This is a discontinued legacy spare part for equipment maintenance replacement.

Function

06-08750101 is Rexroth shielded power cable for nutrunner servo motor.It transmits three-phase power from servo drive to tightening spindle motor.The overall shielding structure suppresses electromagnetic interference in workshop environment to guarantee stable motor operation under dynamic torque load.It withstands frequent bending in continuous tightening cycles.It acts as power transmission medium between drive unit and servo spindle.

Installation

Route 06-08750101 along designated cable channel,fix cable ties and connect both end connectors.Make sure connectors are fully locked.Check shielding grounding before system power-on.

Interface

‑Spindle motor side plug connector

‑Drive unit side plug connector

‑Integrated shield grounding terminal

Circuit feature

Overall copper braid shielding structure,resists electromagnetic interference from workshop servo equipment,good bending resistance for motion workstation.

Feature

06-08750101 is obsolete Rexroth spare part.Typical faults:power interruption,connector pin corrosion,cable insulation aging,inner conductor breakage under repeated bending.Inspect cable insulation,inner conductors and connector pins before replacement.This cable must match corresponding Rexroth tightening spindle and drive,direct replacement without inspection is not recommended.

Diagnostic

When cable breakage,poor contact or shielding failure occurs,system will report overcurrent or motor power abnormal alarm.

Built‑in function:Three-phase power transmission for servo nutrunner,electromagnetic shielding,anti-bending performance,used as Rexroth servo tightening system spare replacement.

Product Brief

06-08750101 is Rexroth shielded servo power cable for nutrunner assembly workstation.Confirm compatibility with matched tightening spindle and drive before ordering.ESD protection required during handling and installation.
