Rexroth 06-08750084 Spare Part

Technical Specifications

Model:06-08750084

Brand:Rexroth

Product type:Torque transducer signal cable

Power supply:Shielded low voltage signal line

Control function:Torque and angle signal transmission,stable signal transfer,anti-interference transmission

Communication:Analog signal transmission

Mounting:Fixed wiring routing

Operating temperature:0~70℃

Storage temperature:-25~80℃

Relative humidity:5~95% non-condensing

Max working altitude:2000m

Weight:0.42kg

Dimension:3000mm8mm8mm

Certification:CE

Protection class:IP65

System compatibility

06-08750084 belongs to Rexroth servo nutrunner tightening system family,matched with torque transducer and tightening controller.Widely applied in automobile assembly bolt tightening workstations.This is a discontinued legacy spare part for equipment maintenance replacement.

Function

06-08750084 is Rexroth shielded signal cable for torque transducer.It transmits precise torque and angle measurement signals from transducer to tightening controller.The full shielding structure suppresses electromagnetic interference in workshop environment to guarantee measuring accuracy.It keeps stable signal transmission during continuous tightening cycles.It acts as signal transmission medium between measuring sensor and control unit.

Installation

Route 06-08750084 along designated cable channel,fix cable ties and connect both end connectors.Make sure connectors are fully locked.Check shielding grounding before system power-on.

Interface

‑Transducer side plug connector

‑Controller side plug connector

‑Integrated shield grounding terminal

Circuit feature

Overall copper braid shielding structure,resists motor and frequency converter electromagnetic interference,suitable for industrial workshop environment.

Feature

06-08750084 is obsolete Rexroth spare part.Typical faults:signal jitter,intermittent disconnection,connector pin corrosion,cable insulation aging.Inspect cable insulation,inner conductors and connector pins before replacement.This cable must match corresponding Rexroth transducer and tightening controller,direct replacement without inspection is not recommended.

Diagnostic

When cable breakage,poor contact or shielding failure occurs,system will report signal abnormal alarm.

Built‑in function:Torque-angle measuring signal transmission,electromagnetic shielding,stable data transfer,used as Rexroth servo tightening system spare replacement.

Product Brief

06-08750084 is Rexroth shielded transducer signal cable for nutrunner assembly workstation.Confirm compatibility with matched torque transducer and controller before ordering.ESD protection required during handling and installation.
