NI PCI-4301 PCI Bus IEEE488 GPIB Interface Board

Technical Specifications

Model:PCI-4301

Brand:NI

Part No:PCI-4301

Product type:PCI Bus GPIB(IEEE488) Interface Board

Channel:1 GPIB channel

Transfer mode:Bus master DMA transfer

Max data transfer rate:1.1MB/s

Function:Talker,Listener,Controller,hardware handshake

Indicator:LED status indicator for GPIB access

Bus:32-bit PCI

Dimension:175mm107mm20mm

Weight:0.19kg

Operating temperature:0℃ ~ +55℃

Storage temperature:-20℃ ~ +70℃

Relative humidity:10~90% non-condensing

Certification:CE

System compatibility

PCI-4301 belongs to NI GPIB instrument control platform.It works with standard PCI industrial PC,supported by NI-488.2 driver and LabVIEW,widely used for communication with GPIB instruments,automated measurement and test system control in legacy ATE systems.It is spare part for legacy test equipment overhaul.

Function

PCI-4301 is PCI GPIB interface board complying with IEEE488 standard.It uses bus master DMA transmission to reduce CPU load,realizes high-speed communication between PC and GPIB test instruments.Supports complete talker,listener and controller functions for multi-instrument synchronous control.

Installation

Insert PCI-4301 into computer PCI slot and fasten bracket.Connect GPIB cable to onboard connector.Install NI-488.2 driver.Take ESD protection before installation.

Interface

‑GPIB IEEE488 connector

‑PCI gold finger edge connector

‑Board status LED indicator

Feature

PCI-4301 classic NI PCI GPIB interface board.Typical faults:GPIB connector pin oxidation,DMA communication failure,controller chip damage.Inspect connector and instrument communication before replacement.

Diagnostic

Fault phenomenon:cannot detect GPIB instruments,communication timeout,data transmission error.Check GPIB shielded cable,PCI slot contact,NI-488.2 driver and instrument address configuration.

Product Brief

PCI-4301 is NI PCI bus IEEE488 GPIB interface board supporting DMA transfer up to 1.1MB/s,used for connecting PC and GPIB measuring instruments,for legacy automated test benches and old ATE equipment renovation.Mainly used for maintenance and replacement of old test equipment.ESD protection must be followed during handling.
