MOOG B97069-061 6+PE Threaded Circular Mating Connector

Technical Specifications

Model:B97069-061

Brand:MOOG

Product type:6+PE Threaded Circular Metal Mating Connector

Standard:EN 175201-804

Structure:Metal shell,thread locking,gold-plated contact pins

Pin definition:6 signal pins + 1 PE protective earth

Protection class:IP65(mated)

Cable outer diameter:8~12mm

Dimension:48mm*18mm

Weight:0.045kg

Operating temperature:-20℃ ~ +120℃

Storage temperature:-40℃ ~ +130℃

Relative humidity:10~90% non-condensing

Certification:CE

System compatibility

B97069-061 is MOOG 6+PE threaded mating connector.It is used for MOOG proportional valves and servo valves,widely used in steam turbine DEH,fatigue test bench and high-precision hydraulic servo system.It is electrical spare part for valve overhaul.

Function

B97069-061 threaded connector transmits 24V power,analog command and feedback signals between controller and proportional/servo valve.Thread locking design provides anti-vibration and stable connection in harsh industrial environment.

Installation

Strip cable and crimp gold-plated contacts,insert pins into connector housing.Screw threaded ring to lock with valve socket.Check wiring continuity and insulation after assembly.Shielded cable is recommended.Take anti-static protection during handling.

Interface

‑6+PE pin cavity,thread locking interface

‑Connector laser marking label

Feature

MOOG IP65 metal proportional valve connector with gold plated contacts.Typical faults:pin corrosion,cable pull damage,poor contact.Inspect contact status during maintenance.

Diagnostic

Fault phenomenon:signal jitter,intermittent connection,valve random alarm.Check connector pins,cable crimping and locking condition.

Product Brief

B97069-061 is MOOG 6+PE threaded circular metal mating connector for proportional valve and servo valve power and signal transmission.It is essential electrical connection spare part for industrial hydraulic control system maintenance and replacement.
