MOOG A02KA4F0VAY Digital Servo Drive

Technical Specifications

Model:A02KA4F0VAY

Brand:MOOG

Product type:Digital Servo Drive

Power supply:380V AC

Communication interface:EtherCAT / digital bus

Function:High-speed closed-loop motor control,position,speed and torque regulation,multi-axis synchronous motion control

Dimension:280mm185mm75mm

Weight:3.2kg

Operating temperature:-20℃ ~ +60℃

Storage temperature:-40℃ ~ +85℃

Relative humidity:10~90% non-condensing

Certification:CE

System compatibility

A02KA4F0VAY belongs to MOOG motion control drive shturl.cc applies to dynamic test equipment,simulation rig and precision forming machinery,widely used in multi-axis high-precision motion control system.It is spare part for legacy automation equipment overhaul.

Function

A02KA4F0VAY is high performance digital servo drive.It realizes real-time closed-loop control of servo motor,supports position,velocity and torque mode,executes multi-axis synchronous movement for industrial motion platform.

Installation

Mount drive in standard electrical cabinet,tighten mounting screws.Connect 380V AC power,motor cable and communication bus.Complete parameter configuration and function test before commissioning.Take anti-static protection during handling.

Interface

‑AC power terminal

‑Motor encoder & power port

‑Digital bus communication port

‑Status indicator & module identification label

Feature

MOOG high reliable digital servo drive.Typical faults:power board damage,communication interruption,encoder signal loss,IGBT aging.Inspect power supply and bus communication before replacement.

Diagnostic

Fault phenomenon:no power,axis alarm,communication offline,motor abnormal operation.Check AC power,encoder wiring,bus connection and drive firmware status.

Product Brief

A02KA4F0VAY is MOOG digital servo drive with high response multi-axis motion control capability,used for industrial test and automation equipment,suitable for automation system maintenance and replacement.Anti-static protection must be followed during handling
