MODICON AS-BDAP-208 Relay Output Module

Technical Specifications

Model:AS-BDAP-208 Brand:MODICON(AEG/Schneider) Product Type:Compact Series 8 Channel Relay Output Module Output Type:Relay contact output Channel Count:8 channels Rating:2A per channel, 24VDC / 230VAC Backplane Bus:Modicon Compact backplane Mounting:Backplane rack slot mount Operating temperature:0℃ ~ +60℃ Storage temperature:-20℃ ~ +70℃ Relative humidity:5%~95%, non-condensing Weight:0.35kg Dimension:115mm90mm70mm Protection:IP20

System compatibility

AS-BDAP-208 belongs to MODICON Compact series relay output module. Compatible with Compact series CPU and backplane. It is used to switch field actuators with relay dry contacts. Suitable for packaging machinery,conveyor systems,small process skid,textile equipment legacy PLC system renovation and replacement as industrial spare part.

Function

AS-BDAP-208 8-channel relay output module. It receives digital on/off commands from MODICON Compact PLC CPU and drives built-in relay contacts to close or open. Dry relay contacts can isolate PLC logic circuit and field power circuit,directly control solenoid valves,auxiliary relays,indicator lights and small contactors. Each channel has LED status indicator for on-site inspection. Built-in surge suppression and hardware self-diagnosis function. Widely used for discrete on-off control in legacy Modicon Compact automation system, serving as reliable relay output spare part.

Installation

Cut off rack power before installation. Insert AS-BDAP-208 module into MODICON Compact backplane slot and lock the card. Check gold finger contact condition. Connect field load wiring to terminal block. Configure I/O address mapping,test relay pull-in and release action,complete function test before formal operation.

Interface

Backplane bus connector,field relay output terminal block,channel status LED indicators for AS-BDAP-208 MODICON relay output module.

Feature

MODICON AS-BDAP-208 Compact relay output card,8 isolated relay channels,2A per contact,dry contact isolation,per-channel LED indication,surge protection,compact rack design,industrial anti-interference design. This discontinued legacy industrial spare part used for old AEG MODICON Compact PLC digital output control maintenance and replacement.

Diagnostic

Module not recognized: check rack power supply,backplane contact and module insertion for AS-BDAP-208. Relay no pull-in: inspect PLC program logic,backplane communication and channel wiring. Contact cannot break: check load short-circuit and relay contact burnout. Intermittent output failure: check terminal loose and electromagnetic interference. LED no light: verify module power supply and channel logic state.

Product Brief

AS-BDAP-208 is AEG MODICON Compact series 8-channel relay output module. It provides dry relay contact outputs to switch field actuators,isolates PLC internal circuit and field power,classic spare part for legacy MODICON Compact PLC automation equipment overhaul.
