MODICON AS-B805-016 Digital Input Module

Technical SpecificationsModel:AS-B805-016 Brand:MODICON Product Type:800 Series 115V AC 16 Point Digital Input Module Signal Input:80~130V AC,47~63Hz,16 points,2 groups of 8 channels Backplane Power:+5V 40mA, -5V 14mA Mounting:Backplane rack slot mount Operating temperature:0℃ ~ +45℃ Storage temperature:-20℃ ~ +70℃ Relative humidity:5%~95%, non-condensing Weight:1.01kg Dimension:260mm140mm30mm Protection:IP20

System compatibilityAS-B805-016 belongs to MODICON 800 series I/O module. Compatible with MODICON 984 series CPU,800 series backplane and RIO remote rack system. It works with other 800 series digital and analog I/O modules. Suitable for metallurgy,chemical,old production line PLC control system renovation and replacement as industrial spare part.

FunctionAS-B805-016 is 16-point AC digital input module. It collects 115V AC discrete on/off signals from field sensors,limit switches and proximity switches,converts field AC signals into internal logic signals and transmits data to PLC CPU. It has channel status LED indication and overvoltage transient suppression protection. Widely used for field digital signal acquisition, serving as reliable PLC I/O spare part.

InstallationCut off rack power before installation. Insert the AS-B805-016 module into MODICON 800 backplane slot and lock the card. Wire field 115V AC input signals to terminal connector. Complete channel signal test via PLC programming software before formal operation.

InterfaceBackplane bus connector,field signal terminal block,channel status LED indicators for AS-B805-016 MODICON digital input module.

FeatureMODICON AS-B805-016 16-channel 115VAC input module,two groups of 8 isolated channels,transient surge protection,LED per channel status display,standard single slot rack design,IP20 cabinet protection. This discontinued legacy industrial spare part used for old MODICON 984 PLC system maintenance and replacement.

DiagnosticModule not recognized: check rack power supply,backplane contact and module insertion for AS-B805-016. No channel signal input: inspect field AC power,switch contact and terminal wiring. Random signal fluctuation: check grounding,surge interference and cable shielding. LED abnormal: verify channel wiring and module hardware failure. I/O data fault: read I/O diagnostic information through Modsoft programming software.

Product BriefAS-B805-016 is MODICON 800 series 16-point 115VAC digital input module. This I/O card acquires field AC discrete signals for MODICON 984 PLC,classic spare part for legacy industrial automation equipment overhaul.
