MODICON ARG 120-166-305 Network Interface Module

Technical SpecificationsModel:ARG 120-166-305 Brand:AEG MODICON Product Type:984 Series MAP3.0 Industrial Network Interface Module Backplane Power:5V DC supplied by rack backplane Communication Protocol:MAP3.0,Modbus Mounting:Backplane rack slot mount Operating temperature:0℃ ~ +45℃ Storage temperature:-20℃ ~ +70℃ Relative humidity:5%~95%, non-condensing Weight:2.15kg Dimension:305mm150mm38mm Protection:IP20

System compatibilityARG 120-166-305 belongs to MODICON 984 series MAP network interface module. Compatible with MODICON 984 series CPU, matching backplane and RIO remote I/O racks. It can connect multiple control stations and upper monitoring hosts through MAP industrial local area network. Suitable for chemical,water treatment,metallurgy,large process control system network renovation and replacement as industrial spare part.

FunctionARG 120-166-305 is dedicated MAP3.0 network interface controller. It realizes protocol conversion and data interaction between MODICON PLC and MAP industrial network, completes data packaging, transmission and node address management. It has built-in communication watchdog and real-time communication fault detection. Widely used for PLC system network interconnection, serving as reliable network communication spare part.

InstallationCut off rack power before installation. Insert the ARG 120-166-305 module into designated backplane slot and lock the board. Check backplane gold finger contact. Connect MAP network cable, set network node address, complete network communication test before formal operation.

InterfaceBackplane bus connector,MAP network port,communication and status LED indicators for ARG 120-166-305 AEG MODICON network interface module.

FeatureAEG ARG 120-166-300 rack type MAP3.0 network interface,standard single slot rack design,built-in communication fault monitoring,stable long-distance industrial data transmission,anti-interference design for workshop environment,IP20 cabinet protection. This discontinued legacy industrial spare part used for old MODICON 984 automation system network maintenance and replacement.

DiagnosticModule not recognized: check rack power supply,backplane contact and module insertion for ARG 120-166-305. Network communication interruption: inspect network cable,shielding grounding and node address setting. Data transmission error: check network terminal resistor and cable aging condition. Status LED abnormal: verify module hardware failure and backplane power. Network fault alarm: read module diagnostic information through Modsoft programming software.

Product BriefARG 120-166-305 is AEG MODICON 984 series MAP3.0 network interface module. It builds MAP industrial network link for MODICON 984 PLC, realizes interconnection of multiple control nodes, classic spare part for legacy large process automation control system overhaul.
