MODICON AM-C916-100 Communication Processor Module

Technical SpecificationsModel:AM-C916-100 Brand:MODICON(Schneider) Product Type:984 Series Communication Processor Module Backplane Bus:Modicon 984 backplane Mounting:Backplane rack slot mount Operating temperature:0℃ ~ +60℃ Storage temperature:-20℃ ~ +70℃ Relative humidity:5%~95%, non-condensing Weight:1.4kg Dimension:260mm140mm30mm Protection:IP20

System compatibilityAM-C916-100 belongs to MODICON 984 series communication processor module. Compatible with MODICON 984 CPU,984 backplane and I/O modules. It acts as network gateway for 984 PLC system. Suitable for chemical plant,water treatment,power plant,large process control distributed network renovation and replacement as industrial spare part.

FunctionAM-C916-100 communication processor module. It is dedicated communication coprocessor for Modicon 984 PLC,undertakes industrial fieldbus protocol processing,realizes data interaction between local rack and remote I/O stations or other PLC nodes. It handles I/O refresh,alarm message transmission and network station management independently,reducing CPU load. Built-in bus monitoring,module self-diagnosis and communication fault alarm function. Widely used for multi-station distributed networking of legacy Modicon 984 automation system, serving as reliable network communication spare part.

InstallationCut off rack power before installation. Insert AM-C916-100 module into MODICON 984 backplane slot and lock the card. Check gold finger contact condition. Connect shielded fieldbus cable. Configure network station address and bus parameters,complete online communication test before formal operation.

InterfaceBackplane bus connector,industrial fieldbus port,run/fault/bus status LED indicators for AM-C916-100 MODICON communication processor module.

FeatureMODICON AM-C916-100 communication coprocessor,offload PLC CPU network task,hardware bus diagnostic,standard single slot rack design,industrial anti-interference design. This discontinued legacy industrial spare part used for old MODICON 984 PLC distributed control network communication maintenance and replacement.

DiagnosticModule not recognized: check rack power supply,backplane contact and module insertion for AM-C916-100. Bus communication interrupt: inspect fieldbus cable,termination resistor,station address and shield grounding. Network overload alarm: verify number of connected network nodes and cable damage. Intermittent data loss: check electromagnetic interference and connector loose. Fault LED lit: check module hardware failure.

Product BriefAM-C916-100 is MODICON 984 series communication processor module. It serves as dedicated network coprocessor for Modicon 984 PLC to implement distributed fieldbus networking,classic spare part for legacy MODICON large industrial automation control system overhaul.

Disclaimer: All parameters are for reference only and shall not be used as the basis for quotation. Goods are scarce, overseas delivery lead time is 3-7 working days. It is only used for equipment maintenance and renovation.
