MODICON 92-01887-02 Network Interface Controller

Technical SpecificationsModel:92-01887-02 Brand:MODICON Product Type:984 Series MAP3.0 Broadband Network Interface Controller Bus Type:MAP3.0 industrial broadband communication Backplane Power:5V DC supplied by rack backplane Mounting:Backplane rack slot mount Operating temperature:0℃ ~ +45℃ Storage temperature:-20℃ ~ +70℃ Relative humidity:5%~95%, non-condensing Weight:1.1kg Dimension:260mm140mm30mm Protection:IP20

System compatibility92-01887-02 belongs to MODICON 984 series MAP3.0 network interface controller. Compatible with MODICON 984 series CPU,backplane and 800 series I/O modules. It can realize interconnection between multiple MODICON PLC stations and upper computer monitoring equipment through MAP3.0 network. Suitable for chemical,water treatment,metallurgy,old production line distributed PLC automation system renovation and replacement as industrial spare part.

Function92-01887-02 MAP3.0 network interface controller. It provides MAP3.0 broadband network interface for MODICON 984 PLC processor,realizes high-speed bidirectional data exchange between multiple PLC nodes and host monitoring system. It supports network address configuration,built-in communication watchdog and module self-diagnosis function. Widely used for industrial multi-node distributed control and data transmission, serving as reliable communication spare part.

InstallationCut off rack power before installation. Insert the 92-01887-02 module into MODICON backplane slot and lock the card. Check gold finger contact condition. Connect MAP3.0 bus cable to module communication port. Set network station address,complete network communication test before formal operation.

InterfaceBackplane bus connector,MAP3.0 bus communication port,network and fault status LED indicators for 92-01887-02 MODICON network interface controller.

FeatureMODICON 92-01887-02 MAP3.0 communication interface card,standard single slot rack design,multi-node peer communication function,real-time LED status indication,built-in communication watchdog,anti-interference design for industrial workshop environment,IP20 cabinet protection. This discontinued legacy industrial spare part used for old MODICON 984 PLC MAP3.0 network maintenance and replacement.

DiagnosticModule not recognized: check rack power supply,backplane contact and module insertion for 92-01887-02. Network communication interruption: check bus cable,termination resistor,shielding grounding and station address setting. Intermittent data error: inspect bus cable damage and connector loose fault. LED abnormal: verify module hardware damage and backplane power supply. Fault alarm: read module diagnostic information through Modsoft programming software.

Product Brief92-01887-02 is MODICON 984 series MAP3.0 broadband network interface controller. It is used for MAP3.0 network connection of MODICON 984 PLC,realizes data exchange between multiple controllers and upper monitoring equipment,classic spare part for legacy industrial automation equipment overhaul.

Disclaimer: All parameters are for reference only and shall not be used as the basis for quotation. Goods are scarce, overseas delivery lead time is 3-7 working days. It is only used for equipment maintenance and renovation.
