MODICON 7628-244734.00 I/O Module

Technical SpecificationsModel:7628-244734.00 Brand:MODICON(AEG) Product Type:Discrete Input Output Module Mounting:Backplane rack slot mount Operating temperature:0℃ ~ +60℃ Storage temperature:-20℃ ~ +70℃ Relative humidity:5%~95%, non-condensing Weight:0.72kg Dimension:260mm140mm30mm Protection:IP20

System compatibility7628-244734.00 belongs to AEG MODICON discrete I/O module. Compatible with MODICON 984 series CPU and backplane. It is used for local rack digital signal collection and output. Suitable for chemical plant,water treatment,packaging machinery,conveyor line old PLC control renovation and replacement as industrial spare part.

Function7628-244734.00 discrete I/O module. It collects on-site digital switching signals and transmits to PLC CPU. Meanwhile receives control commands from CPU and outputs switching signals to field actuators such as solenoid valves and relays. Built-in hardware self-diagnosis and channel fault detection function. Widely used for on-off signal acquisition and output of industrial automation control system, serving as reliable I/O spare part.

InstallationCut off rack power and field load power before installation. Insert 7628-244734.00 module into MODICON backplane slot and lock the card. Check gold finger contact condition. Connect field I/O wiring to terminal block. Configure channel mapping,verify input and output actions and complete function test before formal operation.

InterfaceBackplane bus connector,field digital I/O terminal block,channel status and fault LED indicators for 7628-244734.00 MODICON discrete I/O module.

FeatureMODICON 7628-244734.00 discrete I/O module,modular rack structure,convenient plug and replacement,hardware self-diagnosis function,industrial anti-interference design. This discontinued legacy industrial spare part used for old MODICON 984 PLC digital signal control maintenance and replacement.

DiagnosticModule not recognized: check rack power supply,backplane contact and module insertion for 7628-244734.00. Input signal no reading: check field sensor power supply and wiring sequence. Output no action: inspect PLC program logic,load power supply and terminal loose. Channel fault alarm: check short circuit and wiring damage. Intermittent signal failure: check electromagnetic interference and connector aging.

Product Brief7628-244734.00 is AEG MODICON discrete I/O module. It collects and outputs digital switching signals for MODICON 984 PLC automation system,classic spare part for legacy MODICON industrial automation equipment overhaul.

Disclaimer: All parameters are for reference only and shall not be used as the basis for quotation. Goods are scarce, overseas delivery lead time is 3-7 working days. It is only used for equipment maintenance and renovation.
