MODICON 6390-042.708853 Low Voltage Switchgear Module

Technical SpecificationsModel:6390-042.708853 Brand:AEG SCHNEIDER Product Type:MLS Series Modular Low Voltage Switchgear Assembly Standard:IEC/EN Structure:Modular assembly, rear/top busbar optional Mounting:Cabinet installation Operating temperature:0℃ ~ +45℃ Storage temperature:-20℃ ~ +70℃ Relative humidity:5%~95%, non-condensing Weight:18.5kg Dimension:600mm800mm250mm Protection:IP20

System compatibility6390-042.708853 belongs to AEG MLS modular low voltage switchgear series. Compatible with MLS series busbar, circuit breakers, contactors and relay protection components. It can be integrated into industrial power distribution cabinet system. Suitable for industrial plant, power network,commercial building primary and secondary power distribution system renovation and replacement as industrial spare part.

Function6390-042.708853 is modular low voltage switchgear assembly. It realizes low voltage power distribution,overload and short circuit protection,local power monitoring. It integrates breaker,contactor,relay and indicator components in one unit. Widely used for industrial workshop power supply and distribution, serving as reliable power distribution spare part.

InstallationCut off upstream power before installation. Fix the 6390-042.708853 assembly inside cabinet with standard bolts. Connect main busbar and outgoing power cables. Complete insulation test and power-on inspection before formal operation.

InterfaceMain busbar connection terminal,outgoing power terminal,status indicator window for 6390-042.708853 AEG SCHNEIDER low voltage switchgear module.

FeatureAEG SCHNEIDER 6390-042.708853 modular low voltage switchgear,flexible busbar layout,quick assembly design,built-in multi-protection function,visual status indicator,stable power distribution for industrial environment,IP20 cabinet protection. This discontinued legacy industrial spare part used for old AEG MLS power distribution system maintenance and replacement.

DiagnosticPower supply interruption: check upstream circuit breaker,busbar connection and cable loose fault for 6390-042.708853. Overcurrent trip: inspect load short circuit,overload and component aging. Indicator abnormal: check auxiliary circuit power supply and relay fault. Insulation failure: test cable insulation and check for damp inside cabinet. Protection malfunction: check relay protection parameter setting and component damage.

Product Brief6390-042.708853 is AEG SCHNEIDER MLS series modular low voltage switchgear assembly. It is used for industrial and commercial low voltage power distribution with integrated protection and monitoring,classic spare part for legacy power distribution equipment overhaul.

Disclaimer:All parameters are for reference only and shall not be used as the basis for quotation. Goods are scarce, overseas delivery lead time is 3-7 working days. It is only used for equipment maintenance and renovation.
