MODICON 170BAM09600 Analog I/O Base Module

Technical SpecificationsModel:170BAM09600 Brand:MODICON(Schneider) Product Type:Momentum Series Mixed Analog Input & Output Base Module Signal Type:4~20mA,0~10V DC Mounting:DIN rail mounting,match Momentum adapter Operating temperature:0℃ ~ +60℃ Storage temperature:-20℃ ~ +70℃ Relative humidity:5%~95%, non-condensing Weight:0.23kg Dimension:140mm85mm50mm Protection:IP20

System compatibility170BAM09600 belongs to MODICON Momentum distributed I/O series. Compatible with Momentum processor adapters and Momentum communication modules. It is used for process analog signal acquisition and regulating output. Suitable for chemical plant,water treatment,heating furnace,packaging machinery distributed control renovation and replacement as industrial spare part.

Function170BAM09600 combined analog I/O base module. It collects analog signals from field transmitters such as pressure,flow,level sensors,converts analog signals to digital data and transmits to Momentum PLC adapter. It also converts digital setpoints from PLC into stable analog output signals to drive control valves and regulators. Built-in overrange detection and hardware self-diagnosis function. Widely used for continuous process closed-loop regulation, serving as reliable analog I/O spare part.

InstallationCut off power before installation. Mount 170BAM09600 module on DIN rail,connect with Momentum adapter. Connect field sensor and actuator wiring to terminal block. Configure signal range,scaling parameters and complete closed-loop test before formal operation.

InterfaceI/O bus connector to Momentum adapter,field analog terminal block,channel status and fault LED indicators for 170BAM09600 MODICON analog I/O module.

FeatureMODICON 170BAM09600 Momentum mixed analog I/O base,support 4-20mA / 0-10V signal,compact DIN rail design,hardware self-diagnosis,industrial anti-interference design. This discontinued legacy industrial spare part used for old MODICON Momentum distributed PLC system analog signal control maintenance and replacement.

DiagnosticModule not recognized: check adapter power supply,bus connection and module insertion for 170BAM09600. Analog reading abnormal: inspect transmitter power supply,signal cable and wiring polarity. No analog output regulation: check actuator wiring and output channel hardware fault. Signal fluctuation: verify shielding grounding and electromagnetic interference. Overrange alarm: check field sensor signal exceeds configured range.

Product Brief170BAM09600 is MODICON Momentum series mixed analog I/O base module. It acquires field process analog signals and outputs analog control signals for distributed closed-loop process control,classic spare part for legacy MODICON industrial automation equipment overhaul.
