MODICON 140ARI03010 Analog Input Module

Technical SpecificationsModel:140ARI03010 Brand:MODICON Product Type:Quantum Series 8-Channel RTD Analog Input Module Channel:8 RTD temperature input points Supported Sensor:Pt100, Pt200, Pt500, Pt1000, Ni100, Ni200, Ni500, Ni1000 Resolution:13 bits Isolation:Galvanic isolation between backplane and field side Backplane Power:5V DC supplied by rack backplane Power dissipation:1W Mounting:Backplane rack slot mount Operating temperature:0℃ ~ +60℃ Storage temperature:-20℃ ~ +70℃ Relative humidity:5%~95%, non-condensing Weight:0.3kg Dimension:260mm140mm30mm Protection:IP20

System compatibility140ARI03010 belongs to MODICON Quantum series RTD analog input module. Compatible with MODICON Quantum series CPU,backplane and Quantum I/O modules. It can be used in local rack or remote RIO rack. Suitable for chemical plant,water treatment,metallurgy,power plant temperature monitoring and process control renovation and replacement as industrial spare part.

Function140ARI03010 8-channel RTD temperature input module. It collects temperature signals from platinum and nickel thermal resistance sensors,convert resistance signal into digital value for PLC processor. It supports 2 wire,3 wire and 4 wire sensor wiring modes. Built-in channel fault detection,open circuit alarm and module self-diagnosis function. Widely used for industrial field temperature acquisition and monitoring, serving as reliable temperature input spare part.

InstallationCut off rack and field sensor power before installation. Insert 140ARI03010 module into MODICON Quantum backplane slot and lock the card. Check gold finger contact condition. Wire RTD sensor cables to module terminal block. Configure module parameters and sensor type,verify each channel reading and complete function test before formal operation.

InterfaceBackplane bus connector,RTD sensor terminal block,channel status LED indicators for 140ARI03010 MODICON RTD analog input module.

FeatureMODICON 140ARI03010 Quantum RTD input module,multi-type thermal resistance support,2/3/4 wire connection optional,per channel open circuit detection,high input impedance,standard single slot rack design,anti-interference design for industrial workshop environment,IP20 cabinet protection. This discontinued legacy industrial spare part used for old MODICON Quantum PLC system temperature signal acquisition maintenance and replacement.

DiagnosticModule not recognized: check rack power supply,backplane contact and module insertion for 140ARI03010. Temperature reading abnormal: check sensor wiring,sensor damage and wire resistance compensation setting. Open circuit alarm: inspect sensor cable breakage and loose terminal. Intermittent signal drift: check cable shielding,grounding and ambient temperature interference. LED abnormal: verify module hardware damage and backplane power supply.

Product Brief140ARI03010 is MODICON Quantum series 8-channel RTD analog input module. It receives signal from Pt100 Pt1000 thermal resistance sensors for industrial temperature monitoring,classic spare part for legacy MODICON Quantum automation equipment overhaul.
