Mitsubishi CM1400DUC-24S IGBT Power Module Unit

Feature & Principle

It adopts sixth-generation IGBT chip with anti-parallel freewheeling diode. It controls high-power on-off switching of DC bus for inverter, rectifier and chopper circuits, converts DC power to adjustable AC output for large drives.

Specifications

Model: CM1400DUC-24S Brand: Mitsubishi Electric Topology: 2in1 dual IGBT VCES: 1200V IC: 1400A Isolation voltage: 4000Vrms VCEsat: 1.9V Cooling: Water / forced air cooling Certification: RoHS, CE

Components & Diagnostics

IGBT silicon chip, freewheeling diode, ceramic insulating substrate, copper baseplate, power terminals and gate terminals. Common faults: short circuit breakdown, gate leakage, thermal fatigue, high thermal resistance, diode failure.

Product Brief

CM1400DUC-24S IGBT module, Mitsubishi power semiconductor spare widely used for medium voltage inverter, wind power converter and heavy industry drive equipment.
