Kollmorgen CR10260 CR Series Analog Servo Drive Spare Part

Technical Specifications

Model:CR10260

Brand:Kollmorgen

Part No:CR10260

Product type:Analog servo amplifier

Input voltage:400V AC three phase

Rated output current:30A

Dimension:340mm200mm240mm

Weight:12.5kg

Feedback interface:Resolver / incremental encoder

Mounting:Cabinet rack mounting

Protection class:IP20

Operating temperature:0~45℃

Storage temperature:-20~70℃

Relative humidity:5~95% non-condensing

Certification:CE

System compatibility

CR10260 belongs to Kollmorgen CR series analog servo drive family,matched with Kollmorgen AKM and 6SM series large frame servo motors,widely used in heavy-duty machine tools,large packaging machinery and material handling systems.This is discontinued industrial spare part for equipment overhaul and maintenance.

Function

CR10260 is high-power legacy analog servo amplifier.It accepts ±10V analog speed or position command signal,realizes closed-loop motor motion control.It supports resolver and incremental encoder feedback,built-in multi-protection including overcurrent,overvoltage,overtemperature.It is commonly used for retrofitting and repairing heavy load analog machine axes.

Installation

Install CR10260 inside electrical cabinet by rack mounting.Connect three-phase power wiring,motor power cable,feedback cable and analog control signal wiring.Fasten terminals,complete shielding and grounding inspection before power-on test.

Interface

‑3 phase 400V AC power terminal

‑Motor power output terminal

‑Resolver / incremental encoder feedback connector

‑±10V analog command port

‑Digital input and output terminal

‑Shield grounding terminal

Circuit feature

Adopts analog closed-loop control circuit,high-power IGBT power stage,comprehensive fault protection circuit,strong anti-interference performance,suitable for heavy-load traditional analog motion control equipment.

Feature

CR10260 is obsolete Kollmorgen spare part.Typical faults:IGBT module damage,electrolytic capacitor aging,feedback circuit failure,internal power supply breakdown,connector corrosion.Test DC bus voltage,output three-phase balance and feedback channel before replacement.

Diagnostic

Drive faults will trigger overcurrent,overvoltage or overtemperature alarm;motor no action,position drift,axis abnormal running.

Built‑in function:Analog command processing,motor power amplification,speed and position closed-loop control,fault safety protection,as Kollmorgen heavy-duty legacy machine tool servo drive spare replacement.

Product Brief

CR10260 is Kollmorgen CR series high power analog servo amplifier,paired with large frame AKM /6SM servo motors for legacy heavy-duty machine tool systems.Confirm power rating,feedback type and control signal before ordering.ESD protection required during handling and installation.
