Kollmorgen CE06250 Servo Drive Spare Part

Technical Specifications

Model:CE06250

Brand:Kollmorgen

Part No:CE06250

Product type:Digital servo amplifier

Input voltage:400/480V AC three phase

Continuous output current:25A RMS

Peak output current:50A

Rated apparent power:17kVA

Dimension:340mm210mm260mm

Weight:10.6kg

Feedback interface:Resolver, incremental encoder,EnDat

Mounting:19 inch rack mounting

Cooling:Built-in fan cooling

Protection class:IP20

Operating temperature:0~40℃

Storage temperature:-20~70℃

Relative humidity:5~95% non-condensing

Certification:CE,UL

System compatibility

CE06250 belongs to Kollmorgen ServoStar CD / CE series rack servo drive family,matched with Kollmorgen AKM,Goldline BH/MH brushless servo motors,widely used in heavy-duty CNC machine tools,metal cutting and forming equipment,large material handling positioning systems.This is discontinued industrial spare part for equipment overhaul and maintenance.

Function

CE06250 is rack-mounted high power digital servo amplifier.It adopts four-quadrant regenerative braking control,supports torque,speed and position operating modes,accept ±10V analog command or step/direction signal.Resolver,incremental encoder or EnDat feedback realizes high precision closed-loop motion control.Built-in auto-tuning,electronic gearing function;overcurrent,overvoltage,undervoltage,overtemperature protection,parameter setting and motor tuning can be completed by dedicated software.

Installation

Install CE06250 inside electrical cabinet by 19 inch rack mounting.Connect three-phase AC power wiring,motor power cable,feedback cable and control signal wiring.Fasten terminals,complete shielding and grounding inspection before power-on test.

Interface

‑400/480V AC three phase power terminal

‑3 phase motor power output terminal

‑Resolver / incremental encoder / EnDat feedback connector

‑±10V analog command / step direction port

‑Digital input and output terminal

‑RS232 communication port

‑Shield grounding terminal

Circuit feature

Digital closed-loop control design,IGBT four-quadrant power stage,integrated dynamic braking circuit,multi fault protection circuit,forced air cooling,strong overload capacity and fast dynamic response.

Feature

CE06250 is obsolete Kollmorgen spare part.Typical faults:IGBT module damage,electrolytic capacitor aging,feedback circuit failure,cooling fan failure,auxiliary power breakdown,connector corrosion.Test DC bus voltage,three-phase output balance and feedback signal before replacement.

Diagnostic

Drive faults will trigger overcurrent,overvoltage,undervoltage or overtemperature alarm;motor no action,position drift,axis abnormal vibration.

Built‑in function:Command signal processing,motor power amplification,speed/torque/position closed-loop control,fault safety protection,as Kollmorgen legacy rack servo amplifier spare replacement.

Product Brief

CE06250 is Kollmorgen ServoStar CD 19-inch rack high power servo amplifier,17kVA rated power,matched with AKM / Goldline BH/MH servo motors for heavy-duty CNC automation systems.Confirm power rating,feedback type and control signal before ordering.ESD protection required during handling and installation.
