ICS TRIPLEX TC-201-01-4M5 Communication Interface Module

Technical Specifications

Model:TC-201-01-4M5

Brand:ICS TRIPLEX

Product type:Trusted communication interface module

System series:Trusted SIS

Bus type:Triple redundant backplane bus

Redundancy:Supports TMR triple modular redundant configuration

Communication interface:Multi-channel serial communication port

Data transmission:High-speed secure data exchange between safety controller and external systems

System supply:18~32VDC

Power dissipation:4.2W

Scan cycle:Consistent with Trusted controller system cycle

Galvanic isolation:Logic and field side isolation

Operating temperature:-20~+60℃

Relative humidity:5~95% non-condensing

Weight:0.44kg

Certification:CE,TÜV,SIL3

System compatibility

TC-201-01-4M5 belongs to ICS TRIPLEX Trusted safety instrumented system and installs in Trusted rack. It serves as data exchange gateway for the safety controller,realizing secure communication between SIS and DCS,local HMI and other peripheral devices.Widely deployed in oil & gas,petrochemical and power plants for ESD and fire & gas safety applications.

Function

TC-201-01-4M5 serves as high integrity communication interface unit of Trusted SIS. It processes safety protocol data transmission and supports TMR 2oo3 hardware voting. The module continuously monitors communication link health and detects link failure.

Installation

Insert TC-201-01-4M5 vertically into dedicated slot of Trusted rack. Wire external communication cables to matched termination assembly. Verify communication link status and fault diagnostics via Trusted engineering software.

Interface

‑Gold finger connector for triple redundant backplane bus

‑Field communication terminal interface

‑Front panel LED indicators for run,comms and fault status

‑Onboard communication protocol processing and link diagnostic circuit

Circuit feature

Compact rugged PCB design,built-in surge protection. Isolated communication architecture reduces external interference,fully compliant with SIL3 functional safety hardware specifications.

Feature

TC-201-01-4M5 is spare Trusted communication interface board for ICS TRIPLEX SIS. Common faults include communication port damage,cable open/short circuit and backplane communication fault. Confirm rack firmware compatibility before replacement.

Diagnostic

When communication link loss,signal abnormality or onboard hardware failure is detected,the module triggers fault alarm and uploads diagnostic messages to safety workstation.

Built‑in function

Secure inter-system communication data transmission,communication link health monitoring and TMR signal voting for Trusted SIS rack,used as SIS communication interface spare replacement.

Product Brief

TC-201-01-4M5 is ICS TRIPLEX SIL3 Trusted communication interface module,used for reliable data interaction between Trusted safety controller and external automation systems in safety instrumented system. Verify system firmware compatibility before ordering. ESD anti-static protection must be followed during handling installation.
