ICS TRIPLEX T9851 Digital Output Field Termination Assembly

Technical Specifications

Model:T9851

Brand:ICS TRIPLEX

Product type:AADvance 8-channel simplex commoned digital output FTA

System series:AADvance SIS

Matching module:T9451 digital output module

Mounting:DIN rail mounting

Output channels:8 commoned digital output channels

Nominal voltage:24VDC,operating range 18~32VDC

Per channel rating:1A

Isolation:1500VAC isolation between field and logic side

Protection:Onboard surge suppression for field wiring

Wire gauge:Max 16AWG

Operating temperature:-20~+70℃

Relative humidity:5~95% non-condensing

Weight:0.58kg

Certification:CE,TÜV,SIL3

System compatibility

T9851 belongs to ICS TRIPLEX AADvance safety instrumented system,DIN rail mounted outside main rack. It serves as field termination and signal conditioning unit for T9451 DO module,transmitting 24VDC safety trip output signals to field solenoid valves and safety relays. Widely deployed in oil & gas,petrochemical and power plants for ESD and fire & gas safety applications.

Function

T9851 serves as high integrity simplex commoned digital output termination unit of AADvance SIS. It provides screw terminal connection,surge protection and signal conditioning for 8-channel safety output signals. It is designed for simplex safety configuration and passes safety trip commands from DO module to field actuators.

Installation

Mount T9851 on standard DIN rail inside control cabinet. Wire field solenoid valves and safety relays to T9851 terminal blocks,connect signal cable from FTA to T9451 digital output module. Verify output status and wiring fault via AADvance Workbench engineering software.

Interface

‑Field screw terminal blocks for 8-channel 24VDC digital output wiring

‑Signal output terminals to T9451 DO module

‑Onboard surge protection circuit

‑Screw type terminals for secure field wiring

Circuit feature

Rugged compact PCB design,built-in surge and overvoltage protection circuit. Commoned output architecture,fully compliant with SIL3 functional safety hardware specifications.

Feature

T9851 is spare simplex commoned DO field termination assembly for ICS TRIPLEX AADvance SIS. Common faults include surge damage,terminal loosening and wiring open/short circuit. Confirm DO module model before replacement.

Diagnostic

When wiring open circuit,short circuit or overload fault is detected,corresponding fault alarm will be displayed on matched T9451 module and uploaded to safety workstation.

Built‑in function

Field 24VDC safety output signal termination,surge protection,signal conditioning and signal transmission for T9451 digital output module,used as SIS simplex DO FTA spare replacement.

Product Brief

T9851 is ICS TRIPLEX SIL3 AADvance 8-channel simplex commoned 24VDC digital output FTA,DIN rail mounted,matched with T9451 DO module for safety solenoid valve and relay wiring termination. Verify system firmware compatibility before ordering. ESD anti-static protection must be followed during handling installation.
