ICS TRIPLEX T9832 Analog Input Field Termination Assembly

Technical Specifications

Model:T9832

Brand:ICS TRIPLEX

Product type:AADvance 16-channel dual isolated analog input FTA

System series:AADvance SIS

Matching module:T9432 analog input module

Mounting:DIN rail mounting

Input channels:16 analog input channels,dual group isolation

Signal:4~20mA loop signal,HART transparent

Onboard resistor:135Ω precision load resistor

Protection:50mA replaceable fuses for each channel

Isolation:1500V galvanic isolation between field and logic side

Wire gauge:Max 16AWG

Operating temperature:-20~+70℃

Relative humidity:5~95% non-condensing

Weight:0.45kg

Certification:CE,TÜV,SIL3

System compatibility

T9832 belongs to ICS TRIPLEX AADvance safety instrumented system,DIN rail mounted outside main rack. It acts as field termination and signal conditioning unit for T9432 analog input module,receiving 4-20mA signals from pressure,temperature and level transmitters. Widely deployed in oil & gas,petrochemical and power plants for ESD and fire & gas safety applications.

Function

T9832 serves as high integrity dual-isolated analog input termination unit of AADvance SIS. It provides screw terminal connection,precision loop resistance and individual fuse protection for 16-channel field analog signals. Dual isolation design reduces cross-channel interference and supports simplex,dual and TMR redundant configurations.

Installation

Mount T9832 on standard DIN rail inside control cabinet. Wire field transmitters to T9832 terminal blocks,connect signal cable from FTA to T9432 analog input module. Verify channel reading and loop health via AADvance Workbench engineering software.

Interface

‑Field screw terminal blocks for 16-channel 4-20mA analog wiring

‑Individual replaceable 50mA fuses per channel

‑Signal output terminals to T9432 AI module

‑Onboard 135Ω load resistor and surge suppression circuit

Circuit feature

Rugged compact PCB design,built-in surge and overvoltage protection. Dual group isolated architecture,fully compliant with SIL3 functional safety hardware specifications.

Feature

T9832 is spare dual isolated analog input FTA for ICS TRIPLEX AADvance SIS. Common faults include blown fuses,terminal loosening and loop wiring open/short circuit. Confirm AI module model before replacement.

Diagnostic

When fuse failure,loop open/short circuit or signal abnormality is detected,corresponding fault alarm will be displayed on matched AI module and uploaded to safety workstation.

Built‑in function

Field 4-20mA analog signal termination,dual galvanic isolation,onboard loop resistance,fuse overcurrent protection and conditioned signal transmission for T9432 analog input module,used as SIS dual isolated AI FTA spare replacement.

Product Brief

T9832 is ICS TRIPLEX SIL3 AADvance 16-channel dual isolated analog input FTA,DIN rail mounted,matched with T9432 analog input module for field transmitter signal termination. Verify system firmware compatibility before ordering. ESD anti-static protection must be followed during handling installation.
