ICS TRIPLEX T8423C Digital Input Module

Technical Specifications

Model:T8423C

Brand:ICS TRIPLEX

Product type:TMR 16-channel digital input module

System series:Trusted T8000 SIS

Bus type:Triple redundant parallel backplane bus

Compatible modules:T8300 / T8314 expander chassis,T8310 expander processor,T8311 expander interface

Redundancy:TMR triple modular redundant hot swap architecture

Field input:120VDC,16 channels

Input type:Dry contact,field switches and safety sensors

Galvanic isolation:2500V

Coating:Conformal coated PCB for corrosive,humid and dusty sites

Operating temperature:0~+60℃

Relative humidity:5~95% non-condensing

Weight:0.52kg

Certification:CE,TÜV,SIL3

System compatibility

T8423C belongs to ICS TRIPLEX Trusted SIS safety instrumented system and installs inside T8300 or T8314 expander rack. It acquires 120VDC discrete signals from field safety switches and contact devices,transmits triplicated validated input data to expander processor. The conformal coating protects PCB circuits against moisture,chemical vapour and dust for offshore or heavy industrial applications. Widely deployed in oil & gas,petrochemical and chemical plants for ESD emergency shutdown and fire & gas safety protection.

Function

T8423C serves as high integrity 16-channel 120V digital input unit of Trusted TMR SIS. It samples field 120VDC discrete signals and adopts TMR 2oo3 hardware voting logic to judge real input status. Each channel continuously monitors open circuit and short circuit faults. It supports hot swap replacement without powering down the safety expansion rack.

Installation

Insert T8423C vertically into dedicated I/O slot of T8300/T8314 expander chassis. Connect field wiring to the corresponding terminal assembly. Verify channel health and fault alarms via Trusted Workbench engineering software.

Interface

‑Gold finger connector for triple redundant backplane bus

‑Field termination interface for 16-channel 120VDC digital input wiring

‑Front panel LED indicators for per-channel run,alarm and fault status

‑Onboard TMR sampling and channel diagnostic circuit

Circuit feature

Conformal coated multi-layer PCB design,built-in surge and overvoltage protection circuit. Triple slice independent signal acquisition and hardware voting design,fully compliant with SIL3 functional safety hardware specifications.

Feature

T8423C is spare conformal coated 16-channel 120V digital input board for ICS TRIPLEX Trusted SIS. Common faults include input channel burnout,field wiring short circuit and backplane contact fault. Confirm field voltage and chassis compatibility before replacement.

Diagnostic

When channel open circuit,short circuit or onboard hardware failure is detected,the module triggers fault alarm and uploads diagnostic messages to safety workstation.

Built‑in function

120VDC field discrete signal acquisition,per-channel line fault monitoring and TMR signal voting for Trusted TMR expansion rack,used as SIS digital input spare replacement.

Product Brief

T8423C is ICS TRIPLEX Trusted SIL3 TMR conformal coated 16-channel 120VDC digital input module,hot swappable for T8300/T8314 expander chassis. Verify system firmware compatibility before ordering. ESD anti-static protection must be followed during handling installation.
