ICS TRIPLEX T8193 Three Slot Shield Blank Module

Technical Specifications

Model:T8193

Brand:ICS TRIPLEX

Product type:Passive three-slot shield blank module

System series:Trusted T8000 SIS

Bus type:No backplane electrical circuit,mechanical filler only

Compatible modules:T8100 controller chassis,all T8000 series rack modules

Redundancy:Passive mechanical shielding design

Power bus:Zero power consumption

Operating temperature:0~+60℃

Relative humidity:5~95% non-condensing

Weight:0.72kg

Certification:CE,TÜV,SIL3 system compliance

System compatibility

This blank shield hardware belongs to ICS TRIPLEX Trusted SIS safety instrumented system and installs inside T8100 rack cabinet. It seals three continuous empty module bays,blocks dust and debris ingress,maintains original airflow path for internal active modules. Widely applied in oil & gas,petrochemical and chemical plants for ESD emergency shutdown and fire & gas safety protection.

Function

T8193 is the passive three-slot filler unit of Trusted TMR SIS. It fills vacant three-slot positions to keep chassis thermal dissipation performance. Its metal shielding structure suppresses electromagnetic interference and protects internal safety modules. It contains no electronic components and will not participate in safety logic or signal processing.

Installation

Insert T8193 vertically into three adjacent empty slots of T8100 Trusted rack. Fasten front panel fixing screws. No power wiring or backplane configuration required.

Interface

‑Front panel screw lugs for rack mounting

‑Metal shielding housing for EMC protection

‑No electrical contact with backplane bus

‑No LED indicators,passive filler panel

Circuit feature

Full metal passive shielding construction,no electronic components. Optimized air baffle design,fully meets SIL3 mechanical and EMC requirements.

Feature

T8193 is spare three-slot blank shield filler for ICS TRIPLEX Trusted SIS. Common issues include loose mounting and surface shielding damage. Confirm slot dimension matches T8100 chassis before installation.

Diagnostic

No built-in electronic diagnosis. Visual inspection to verify intact shielding surface and secure installation.

Built‑in function

Three-slot bay sealing,airflow retention and electromagnetic shielding for Trusted TMR safety rack,used as SIS chassis blank spare replacement.

Product Brief

T8193 is ICS TRIPLEX Trusted SIL3 three-slot passive shield blank module for T8100 chassis. Check chassis compatibility before purchase. ESD protection must be followed during handling and installation.
