ICS TRIPLEX T8100 Controller Chassis

Technical Specifications

Model:T8100

Brand:ICS TRIPLEX

Product type:TMR controller chassis

System series:Trusted T8000 SIS

Bus type:Triple redundant parallel backplane bus

Compatible modules:Trusted processor boards,AI/DI/DO I/O modules,power supply modules,communication interface cards

Redundancy:TMR triple modular redundant hot swap architecture

Power bus:24VDC

Operating temperature:0~+60℃

Relative humidity:5~95% non-condensing

Weight:5.50kg

Certification:CE,TÜV,SIL3

System compatibility

This chassis hardware belongs to ICS TRIPLEX Trusted SIS safety instrumented system and serves as the main rack cabinet. It carries TMR processor, I/O modules and power units, provides stable triple redundant backplane bus interconnection. It communicates with system engineering workstation,widely deployed in oil & gas,petrochemical and chemical plants for ESD emergency shutdown and fire & gas safety protection.

Function

T8100 serves as the high integrity mechanical and electrical rack unit of Trusted TMR SIS. It provides physical installation slots and redundant backplane bus for all system modules. It continuously runs backplane self-diagnosis to detect bus connection abnormality,slot contact failure and power distribution fault in real time. Its TMR bus design prevents system breakdown caused by single backplane channel failure.

Installation

Mount the T8100 chassis to standard 19-inch cabinet. Insert processor and I/O modules vertically into dedicated slots,complete power wiring and backplane bus connection,verify bus communication status and fault diagnosis via Trusted Workbench engineering software.

Interface

‑Triple redundant backplane bus connector for module intercommunication

‑DC power terminal block for rack power input

‑Multiple dedicated slots for processor, I/O and communication modules

‑LED indicators for rack power, bus running, alarm and fault prompt

Circuit feature

Conformal coated backplane PCB design,built-in surge and overvoltage protection circuit. Triple channel hardware bus voting design,fully compliant with SIL3 functional safety hardware specifications.

Feature

T8100 is a spare controller chassis for ICS TRIPLEX Trusted SIS system. Common faults include backplane circuit damage,slot contact failure and power distribution fault. Confirm module slot definition and bus compatibility before replacement.

Diagnostic

When backplane disconnection,slot contact failure or hardware breakdown is detected,the chassis will trigger fault alarm and upload diagnostic messages to safety workstation.

Built‑in function

Module mechanical mounting and triple redundant backplane bus communication for Trusted TMR safety rack,used as SIS controller chassis spare replacement.

Product Brief

T8100 is ICS TRIPLEX Trusted SIL3 TMR controller chassis,supporting TMR triple modular redundant hot swap architecture. Verify module compatibility before ordering. ESD anti-static protection must be followed during handling installation.
