ICS TRIPLEX T8030S OPC Server Package

Technical Specifications

Model:T8030S

Brand:ICS TRIPLEX

Product type:TMR OPC server package

System series:Trusted T8000 SIS

Bus type:Ethernet redundant communication bus

Compatible modules:Trusted processor boards,AI/DI/DO I/O modules,backplane base units,redundant power supply

Redundancy:Single / dual redundant hot swap communication architecture

Supported OPC standard:OPC DA v1.0,v2.05a,OPC A&E v1.1

Max supported controllers:32 Trusted controllers

Update rate:10ms minimum

Event timestamp:1ms resolution

Operating temperature:0~+60℃

Relative humidity:5~95% non-condensing

Certification:CE,TÜV,SIL3

System compatibility

This communication software package belongs to ICS TRIPLEX Trusted SIS safety instrumented system and connects with Trusted safety controllers via Ethernet. It transfers real-time process tags,alarm messages and sequence of events data to SCADA,HMI and historian workstation,widely deployed in oil & gas,petrochemical and chemical plants for ESD emergency shutdown and fire & gas safety protection.

Function

T8030S serves as the high integrity OPC communication unit of Trusted TMR SIS. It executes safety data transmission commands,provides OPC interface for upper monitoring system to access safety controller data. It continuously runs self-diagnosis to detect ethernet link break,data transmission error and communication hardware fault in real time. Its dual redundant network design prevents communication interruption caused by single link failure.

Installation

Install the software package on Windows industrial workstation. Complete ethernet cable wiring between workstation and Trusted controller,verify data link status and fault diagnosis via Trusted Workbench engineering software.

Interface

‑Dual Ethernet port for redundant network connection

‑OPC DA and OPC A&E standard interface for upper system

‑Onboard data tag mapping and event timestamp function

‑Status indicators for communication running,alarm and fault prompt

Circuit feature

Industrial workstation compatible service program,built-in data verification and anti-interference algorithm. Dual channel redundant communication design,fully compliant with SIL3 functional safety hardware specifications.

Feature

T8030S is a spare OPC server software package for ICS TRIPLEX Trusted SIS system. Common faults include network port failure,tag mapping error and communication cable fault. Confirm controller firmware version before deployment.

Diagnostic

When ethernet link disconnection,data transmission error or communication breakdown is detected,the package will trigger fault alarm and upload diagnostic messages to safety workstation.

Built‑in function

Redundant OPC safety data transmission and communication self-diagnosis for Trusted TMR safety system,used as SIS upper monitoring communication spare replacement.

Product Brief

T8030S is ICS TRIPLEX Trusted SIL3 OPC server package,supporting single / dual redundant ethernet architecture. Verify controller firmware compatibility before ordering. ESD anti-static protection must be followed during hardware installation.
