Huttinger NTM243P61_GOOD DC Power Module

Technical Specifications

Model：NTM243P61_GOOD Brand：Huttinger Product Type: Industrial DC power supply module

Module Feature

Huttinger NTM243P61_GOOD is high performance DC power module designed for Huttinger RF power supply system. It provides stable DC power supply for RF amplifier and control circuits. It has low output ripple and built-in multi-protection function. Widely applied in semiconductor PVD, CVD and plasma etching vacuum equipment. Working principle: DC power conversion Application frequency:13.56MHz Onboard components: Power conversion circuit, filter unit, overcurrent protection parts, connecting terminals

LED indicators

Not equipped

Hardware self-diagnosis

Output voltage test, insulation resistance test, load performance inspection

Programming software

No dedicated software required

Electrical Parameters

Working voltage: 24VDC Application: Matched with Huttinger TIG series RF generator

Mechanical & Structure

Mounting: Installed inside RF generator cabinet Protection class: IP20

Environmental

Operating temperature:10℃ ~ +45℃ Ambient humidity:5~85% non-condensing Certification: CE Status: Huttinger DC power module

System compatibility

NTM243P61_GOOD is compatible with Huttinger TIG series RF generator and matching network for semiconductor vacuum plasma processing equipment.

Function

NTM243P61_GOOD is DC power module manufactured by Huttinger. It converts input AC power to stable 24V DC to supply power for RF generator internal control and amplifier units. It has built-in overvoltage, overcurrent and overheat protection. Low noise design adapts to high electromagnetic environment. It is essential spare for RF generator maintenance.

Installation

Follow lockout/tagout safety procedure before installation. Cut off all power and discharge high voltage components. Open RF generator cabinet, replace the old power module. Check wiring terminals and insulation clearance. Close cabinet, restore power, run power output test and alarm inspection.

Interface

DC power connecting terminals, fixed mounting holes, no LED indicators on NTM243P61_GOOD.

Diagnostic

No DC output: Damaged module or loose power wiring. Unstable DC voltage: Component aging or poor terminal contact. Overheat alarm: Blocked cooling channel or module overload.

Product Brief

NTM243P61_GOOD Huttinger DC power supply module,matched with TIG series RF generator,used for semiconductor vacuum plasma coating and etching equipment maintenance,power supply spare part.
