Honeywell 51196694250 Operator Interface Board

Technical Specifications

Model:51196694250

Brand:Honeywell

Product type:FSC front panel operator interface board

System series:FSC Fail Safe Controller SIS

Bus type:Parallel backplane system bus

Compatible modules:FSC main controller,system backplane,communication boards and I/O modules

Redundancy:Supports DMR dual modular redundant / QMR quadruple modular redundant configuration

Power bus:5V DC,24V DC power supply

Operating temperature:0~+60℃

Relative humidity:5~95% non-condensing

Weight:4.18kg

Certification:CE,TÜV,SIL3

System compatibility

This front panel hardware belongs to Honeywell FSC safety instrumented system,installed on the front cabinet of FSC safety rack. It establishes direct interaction access between field technicians and the safety controller. It synchronizes running data and alarm events to the main controller and works with Experion PKS DCS. Widely applied in oil & gas,petrochemical and chemical sites for ESD emergency shutdown and fire and gas safety protection.

Function

51196694250 acts as the local human-machine interface unit of FSC SIS. It integrates physical function buttons and multi-color LED indicators to display system operating status,interlock alarms and fault codes. Field operators can carry out local inspection and simple manual operations without relying on remote HMI workstation.

Installation

Mount the board onto the front panel frame of FSC rack. Connect backplane power and signal cables,verify button responsiveness and LED indication status via Honeywell FSC engineering software.

Interface

‑Gold finger connector for backplane bus signal interconnection

‑Built-in physical buttons for local operation

‑Multi-group LED indicators for running,alarm and fault status

‑Internal signal traces for data exchange with main controller

Circuit feature

Adopts conformal coated multi-layer PCB layout,with built-in signal isolation circuit to resist harsh industrial electromagnetic interference. Button and indicator circuits support continuous self-check,meeting SIL3 functional safety requirements.

Feature

51196694250 is a replacement spare front panel board for Honeywell FSC SIS series. Common defects include button contact fatigue,LED lamp damage and gold finger corrosion. Check rack panel size and firmware compatibility before replacement.

Diagnostic

Once panel communication failure,button circuit breakdown or indicator abnormality is detected,the system will capture fault records and transmit diagnostic information to safety monitoring workstation.

Built‑in function

On-site system status display and local manual operation for FSC safety rack,used as SIS front panel spare replacement.

Product Brief

51196694250 is Honeywell FSC SIL3 front panel operator interface module,supporting DMR/QMR redundant setup. Confirm rack cabinet compatibility before ordering. ESD anti-static protection is required during handling and installation.
